System
|
SoC : Linux SoC operation system:Linux
|
|
Storage
|
Built-in SATA interface x4, compatible with
|
|
SATA/SATAII/SATAIII Hard disk(Max. 16TB)
|
|
Video And Other I/O Interface
|
Dual video output : HD/VGA output
|
|
USB 2.0 x2 – connect with mouse and USB device
|
|
Auto-MDIX. Ethernet x1- 10/100/ 1000
|
|
(IEEE 802.3 Type 10Base-T、IEEE 802.3u Type 100Base-TX)；
|
|
Auto-MDIX
|
|
Network Protocol
|
Ipv4 / ARP / TCP / UDP / ICMP / SMTP / HTTP / RTP / RTSP / RTCP
|
|
Video Format
|
Support H.265 compression format
|
|
Live / Playback
|
. VGA at 30 FPS mode, capable monitoring
Max.16 channel real-time video.
|
|
Up to 4 channels of real-time video monitoring in
1080P@30 fps mode.
|
|
Max.4 channel video playback by 1080P@ 30fps,
Max.16 channel VGA@ 30fps.
|
|
The real-time monitor screen support channel switch
display—the single channel switch, group channel switch
|
|
Record files playback can search by time and event.
(IPCam displacement)
|
|
Playback speed : Slow motion / fast motion multi-playback
speed, single image format(forward or reverse)
|
|
Capable doing multi-works as real-time monitoring,
recording and playback at same time
|
|
Event Notification
|
Event report content: Camera displacement detection,
camera disconnection, hard disk damage.
|
|
Recording Mode
|
Constant recording
|
|
Schedule recording
|
|
Motion Detection recording
|
|
Backup Management
|
Backup output format: MP4
|
|
USB flash drive removable storage device
|
|
System Management
|
Provide remote Client software, capable doing PC
setting, real-time monitor and playback.
|
|
Hierarchical user right management, can setting user
access rights or administrator, max.10 groups account.
|
|
Support 3 user login in and use real-time monitoring
function by client software or browser at same time.
|
|
System usage records, record user login time, IP,
monitoring images.
|
|
MS IE11 Browser: Support MS IE11
|
|
Device Support
|
Support megapixel IP Camera monitor images
|
|
Power
|
DC12V / 6A
|
|
Operating Temperature
|
0-45 ℃
|
|
Weight
|
About 4.2KG |
|
Size
|
430mm x 370mm x 96mm (W x D x H)
|
