Mobile Surveillance

Mobile DVR

VVH-MD82D(4GA)

8CH / 1080P / 3G / 4G / WIFI / H.265 / SD Card / HDD / GPS

  • DC 8~36V

  • G-Sensor

  • Alarm

  • TVout

  • GUI

  • -20~65°C

  • Audio External

  • SATA

  • delayed

  • ADAS

  • DSM

Download Catalog

Product Features

  • The firmware integrates intelligent AI algorithms. (Option)
    With ADAS camera, it can detect/alert/notify the dangerous road conditions in front of
    the vehicle in real time.
    With DSM camera, it can detect/alert/notify drivers of fatigue or distracted driving behaviors.
  • With a wireless network (LTE or WiFi) module and Fuho's GMS fleet, you can monitor and control
    your car's driving status at any time remotely.
  • A reliable list makes it easier to search for video records.
  • Hidden file format with particular player for files security and provide AVI, MP4 conversion
    function, so that users can directly play in the general environment"
  • With G-Mouse, recording of driving footage and speed
  • Integrated G-sensor function detects shocks and triggers mandatory recording so that important
    event videos are not lost.
  • Integrated power management funtion supports parking surveillance after ignition off.

Video Format

NTSC / PAL

OS

Embedded Linux

Video Input

8 Cameras

Camera Power Output

8 Power, 12V / 400mA

Video Output

x1 Video Output (optional VGA or CVBS)

Audio Input

x2 Audio Input

Audio Output

x1 Audio Output

Alarm I/O

x6 Alarm Input ; x2 Alarm Output

Operation Interface

GUI

Language

English/ Traditional Chinese/ Simplified Chinese

Display

NTSC

240 Fps

PAL

200 Fps

Recording Frame

NTSC

8CH 1080P@15FPS/CH ; 720P@30FPS/CH

PAL

8CH 1080P@15FPS/CH ; 720P@30FPS/CH

Display Mode

1ch / 4ch / 9ch

Simplex Mode

Record / Playback

Resolution

Display

CVBS

NTSC 960 x 480  / PAL 960 x 576

 VGA

800 x 600

Recording

NTSC

1920 x 1080@1080P

1280 x 720@720P

960 x 480@960H

720 x 480@D1

PAL

1920 x 1080@1080P

1280 x 720@720P

960 x 576@960H

720 x 576@D1

Storage

2.5”Removable SATA HDD / SD Card

Backup Device

Usb 2.0 Flash Driver、2.5”SATA Removable HDD

Playback

Mode

Time / Date, Events

Full Screen

Yes

Led Indicator

4 Led (LAN、REC、GPS、POWER)

Signal Loss Detector

Yes

Buzzer Alarm Output

Yes

RS232

Yes

GPS

Yes (Optional G-mouse)

G-sensor

Yes

3G/4G

Yes (Optional VVH-MD82D-3GA)

WiFi

Yes (Optional )

IR Remoter

Yes

Watchdog

Stop, Automatically Return To Recording Mode When Power Back.

Power Supply

(1) DC 8V~36V

(2)Acc Extended Recording By Setting Software.

Dimension

250mm x 174.8mm x 69.5mm

Operate Temperature

-20°C~65°C

Weight

1.85kg (With Bracket And HDD )





DESCRIPTION

Advanced Driver Assistance Systems, ADAS
Pedestrian Collision Warning, (PCW), Forward collision warning(FCW),
Headway Monitoring & Warning (HMW), Lane Departure warning (LDWS)

 Driver Status Monitor, DSM
Distraction warning (head up/down/looking left/right),
talking on the phone, smoking, fatigue driving (eyes closed/yawning),
abnormal (driver leaving seat/blocking camera), not wearing a mask, etc.
