CCTV Camera
5MP / IP66 / Bullet / IR
DC12V
LENS 3.6mm
30M
0.1 LUX
50dB
1/2.8"CMOS
4 LEDs
-20~50°C
Product Features
Pick Up Element | 1/2.8" CMOS sensor |
Video System | NTSC / PAL |
Image Signal Process | Digital Signal Processor |
Lens | 3.6 mm |
Number Of Pixel | 2592 (Horizontal) x 1944(Vertical) |
Horizontal Resolution | 5M@20fps |
Power Supply | DC 12 ± 1V |
Power Consumption | 120mA (IR Off);340mA (IR On) |
ICR | Support |
Electronic Shutter | 1/50(1/60)sec ~ 1/50,000sec |
White Balance | Auto |
Gain Control | Auto |
S/N Ratio | ≥50dB |
Day Night Auto Switch | Support |
LEDs | 4 PCS |
IR Range | 30M |
IR Wavelength | 850nm |
Minimum Illumination | 0.1Lux |
OUTPUT | AHD、TVI、CVI、CVBS |
Language | English / Simplified Chinese / Traditional Chinese /German / French / Italian / Spanish /Polish / Russian /Portuguese / Dutch / Turkish / Japan |
IP Rating | IP66 |
Operating Temperature | -20℃~50℃ |
Dimensions (H×W×D) | 190mm x 71mm x 59 mm |
Weight | About 310g |
Simliar Product
Update Date 2021/12/07 | VCF-5M60U | VCF-5560U | VCT-5660U |
Resolution | 5MP | 1080P | 1080P |
Pick Up Element | 1/2.8" CMOS | 1/3" CMOS | 1/2.9" CMOS |
LENS | 3.6mm | ||
LEDS | 4 PCS | ||
IR | ✓ | ||
IR Wavelength | 850nm | ||
IR Range | 30m | ||
Sensitivity | 0.1Lux | F1.2 0.003 LUX / 200MV | |
OUTPUT | AHD、CVBS、TVI、CVI | ||
Waterproof | IP66 |
Update Date 2021/12/07 | VCN-SH5960U | VCN-S5960U |
Resolution | 1080P | 1080P |
Pick Up Element | 1/2.8" CMOS | 1/2.8" CMOS |
LENS | 3.6mm | |
LEDS | 4 PCS | |
IR | ✓ | |
IR Wavelength | 850nm | |
IR Range | 30m | |
Sensitivity | 0.01Lux | |
Starlight Color | ✓ | |
OUTPUT | AHD、CVBS、TVI、CVI | |
Waterproof | IP66 |
*If the above specifications are different, please refer to the latest date
Download support
Download Manual
Product Model | Download | Explanation |
VCF-5M60U | V.01 |
