| Terms |
Specification |
| Video Input |
4CH 720P 360°surround view camera
1CH parking assist camera (optional) |
| Resolution |
720p 360°surround view cameras：CH1(Front)+CH2(Right)+CH4(Left)+CH3(Rear), auto activate parking assist image.
Default recording: ch 25/30 fps. |
| Power |
- DC12V, Max power approx. 1.25A.
- DC12V, ACC OFF, power approx.30mA.
- Working Voltage：DC8.0v ~ DC32.0v.
- Activate Voltage>DC11v.
|
| Delay Record function |
- ACC OFF, delay power support for approx.3 sec.
- Built-in supercapacitors delay recording time approx.3sec, and then write buffer record data back to SD card.
|
| Temperature |
Operation Temperature：-20℃～60℃ (Non-confined spaces with natural ventilation)
Storage Temperature：-40℃～85℃ |
| Storage |
SanDisk class10 and 8G above SDHC card.
Some specific devices require the vendor recognizes SD card |
| Recording |
Automatic recording after activate device in 30sec. |
| Recoding Contents |
Image, Data, Audio, GPS info (optional). External trigger signal and G-sensor data. |
| Storage Format |
Using specific file format, require dedicated player
Directly playback on the device. |
| Audio Input |
Using specific signal format, require dedicated play monitor |
| Time setting |
(a)Auto GPS adjustment, active calendar clock when device cannot receive GPS signal.
(b)The first time device installment requires use GPS time adjustment. After finished the adjustment, RTC time will support by vehicle power. The time has to reset if device power off. |
| Display |
TV-Out Video output
AV-Out Audio output.(AV terminal) |
| Dimension |
115mm x 132.7mm x 30mm (Width x Depth x Length) |
| Weight |
0.4kg (Include SD Card) |
