CCTV Surveillance System

CCTV Camera

FUM-TC810

720P / Bullet

  • DC12V

  • 1/4"CMOS

  • Alarm

  • IVS

  • -20~65C

  • 57°

Download Catalog

Product Features


  • 1/4" CMOS Image sensor
  • AI Intelligent temperature sensing HD camera.
  • Temperature measurement does not affect by other objects,
  • only for face detection.
  • Instant non-contact measurement to avoid infectious diseases.
  • Detecting distance1.5~2m.
  • Temperature compensation can be adjusted according to the environment
  • (OSD menu).
  • Menu operation can be controlled by remote control.
  • Warning of over-temperature and not wearing a mask.
  • Built-in warning audio speaker.
  • External alarm supported.
Image component

1/4" CMOS image sensor
Signal mode NTSC/PAL
Video signal processing system Digital Signal Processing System
View angle Image vision 57°c (135°F)
Temperature measurement vision 33°c(92°F)
Effective Pixels Image resolution 1296(H)×736(V)
Effective temperature measurement pixels 32(H)x32(V)
Input voltage DC12V 1.5A
Power consumption 170mA~280mA (audio)
Video Mode Intelligent video processor
AI Model Deep Neural Network Processor
Temperature measurement technology Thermopile far-infrared sensor
Temperature measurement distance >3 meters
Best distance for temperature measurement 1~1.5m
ITemperature measurement response time <1Sec
Working temperature -20~65°c
Storage temperature -40~85°c
Voice Output Speaker Output 8Ω2W
Video Output analog HD/HDMI alternative
Face detection degree (measurement rate) 1~5 people (95%↑)
Temperature measurement distance and temperature deviation 1m↓±0.3°c / 3m↓±0.5°c
Support language Traditional Chinese & English
Simplified Chinese & English Alternative
Operating temperature Image sensor -30°c~85°c
Temperature sensor 15~42°c
Dimensions (W×D×H) 205mm x 93mm x 83 mm
weight About 700g

Download support

Download Manual

　 　 　 　 　 　 　 　 　 　
Product Model DownloadExplanation
FUM-TC810 User Manual V2.0
