Mobile Surveillance

Vehicle Image Server

GMSERVER mini PC

40ch / H.264 / H.265 / HDD

  • H.264

  • H.265

  • Linux系統

  • DC 19V

  • 0~40°C

  • SATA

Download Catalog

Product Features

  • Use Intel CPU J4005
  • able to install one 2.5 inches HDD/SSD,Maxent 2.5T
  • support New H.264/H.265 Compression, save space of storage
  • use Embedded Linux system, protect device to avoid various
  • Max. support 40 devices online at the same time
  • support HD OUT and USB 3.0 etc
Main Processor Intel® Celeron® J4005
Memory 8GB DDR4 RAM
Hard Disk 1TB (MAX. 2T)
Network 1 x Gigabit RJ-45 Ethernet port
USB 4 x USB 3.0
Button Power button
Power Supply DC 19V
Video Output HD OUT x2
Size 115x111x51mm
Working Temporary Temporary: 0~40°C(Celsius), Humidity: 90%
Support Devices Max. 40 devices
Record Mode Normal record/Event record
Network Protocol Ipv4 / ARP / TCP / UDP / ICMP / HTTP
System Management Able to use Chrome to do the setting
/ remote playback/live view
Account management
