Car Cameras
Product Features
|
Pick Up Element |
1/2.8" CMOS sensor |
|
Video System |
NTSC / PAL |
|
Image Signal Process |
Digital Signal Processor |
|
Lens |
2.8mm |
|
Number Of Pixel |
1920 (Horizontal) x 1080(Vertical) |
|
Horizontal Resolution |
1080P@30fps |
|
View Angle |
H:95° |
|
Power Supply |
DC 12 ± 1V |
|
Power Consumption |
120mA(IR Off)；200mA(IR On) |
|
ICR |
Support |
|
Electronic Shutter |
AUTO/1/50(1/60)sec ~ 1/50,000sec |
|
White Balance |
Auto |
|
Gain Control |
Auto |
|
S/N Ratio |
≥50dB |
|
Day Night Auto Switch |
Support |
|
LEDs |
12 PCS |
|
IR Range |
15M |
|
IR Wavelength |
850nm |
|
Minimum Illumination |
0.01 LUX |
|
OUTPUT |
AHD or CVBS (Default setting: AHD Mode) |
|
Language |
English / Simplified Chinese / Traditional Chinese / German / French / Italian / Spanish /Polish / Russian / Portuguese / Dutch / Turkish |
|
IP Rating |
IP66 |
|
Operating Temperature |
-20℃~50℃ |
|
Dimensions (H×W×D) |
Φ 120 x 60 mm |
|
Weight |
About 300g |
| Update Date 2022/01/25 | AVM-S282C | AVM-S382C |
| Resolution | 1080P | |
| Pick Up Element | 1/2.9" Sony Exmor CMOS | 1/2.8"CMOS |
| Lens | 2.8mm / 3.6mm | 2.8mm |
| LEDS | 12 pcs | |
| IR | ✓ | |
| IR Range | 15M | |
| Sensitivity | 0.01 LUX / F1.2 (IR ON) | 0.01 LUX |
| View Angle | H95° / H85 ° | H95° |
| Waterproof | IP66 | |
*If the above specifications are different, please refer to the latest date
