Video System
|
NTSC PAL
|
|
Pick Up
|
1/2.8" SONY CMOS Sensor
|
|
Number of Pixel
|
1920(H)×1080(V)
|
|
Effective Pixels
|
2.0 Mega Pixel
|
|
Resolution
|
1080P
|
|
Sync System
|
Internal
|
|
Scanning system
|
2 : 1 Interlace
|
|
Sensitivity
|
0.01 LUX
|
|
S/N Ratio
|
≥50dB
|
|
Auto Gain Control
|
Auto
|
|
Mirroring
|
Optional(BV)
|
|
White Balance
|
Auto
|
|
Electronical Shutter
|
Auto: 1/30NTSC(1/25 PAL)S TO 1/50,000S
|
|
Video Output
|
1 Vp-p Composite Video Output, 75 Ohms
|
|
Power Supply
|
DC 12.0V/DC5.0V
|
|
Power Consumption
|
80mA/200mA
|
|
Lens
|
2.8mm
|
|
View Angle
|
H:110˚
|
|
Waterproof
|
IP66
|
|
Operating Temperature
|
- 10° C ~ + 60°C
|
|
Dimensions (H x W x D)
|
45 x 53 x Ø30 mm
|
|
