IP Surveillance System



Cloud Comprehensive Controller 1080

  • DC12V

  • -10~50°C

  • Two-way

Download Catalog

Product Features

  • SD Card Recording & Cloud Server Recording
  • P2P Remote Aceess Support for Cyber Security
  • 2MP Full HD Security Camera Support Safety Double up
  • Turn on and off the Light from Smart Phone or PC in Visibility
  • x4 Relay Controller Appliable for Light, Lock and Electrical Applinace
  • USB Type A Built in for WiFi Dongle and USB Communications
  • RS485, RS232 and Alarm in are Available
  • Intercom Support
Power Input DC 12V / 1A
Voltage Proof of the
the Relay Contact Point
7A@250VAC / 7A@30VDC
Remote Access Smart Phone App / IE Browser
Network Interface 10/100 Mbps Ethernet / RJ45 Connector
Browser Microsoft Internet Explorer 11
Video Configuration via IE DHCP Default Setting
Video Configuration via IE Video : Brightness、 Contrast、Saturation、 Baud Rate
Audio : ON/OFF & Volume
Video Input AHD 1080P
Live View 1080/30fps
Recording VGA/10fps
Audio x1 Audio Input / x1 Audio Output
Storage SD Memory Card
(SDHC Card 16GB Class 10 above)
USB Connection x1 USB Type A / USB WiFi Dongle
Garage Door Control Up/Down/Stop
Crush Injury Protection x2 Alarm Input Support
LED Indicator Red - Record / Green - Power / Blue - Lan
Control I/O x1 RS485 & x1 RS232
x4 Relay Contact Points(x3 Always Open x1 Always Open & Always Close)
x2 Alarm Input
Ambiant Temperature -10°C ~ 50°C
Measurements 113.5 x 95 x 50mm
