CCTV Surveillance System

CCTV Camera

VCF-5760U-A

1080P / IP66 / Bullet / IR

  • DC12V

  • LENS 3.6mm

  • 30M

  • 0.1 LUX

  • 58dB

  • 1/3CMOS

  • 4 LEDs

  • -20~50°C

Download Catalog

Product Features

  • 1/3" CMOS sensor
  • AHD1080P high video quality transmission,up to 1920x1080 pixels
  • 3.6 mm lens
  • TVI support coaxial
  • AHD or CVBS or TVI or CVI output switch
  • IP Rating: IP66
Pick Up Element 1/3" CMOS sensor
Video System NTSC/PAL
Image Signal Process Digital Signal Processor
Lens 3.6mm
Number Of Pixel 1920 (Horizontal) x 1080(Vertical)
Horizontal Resolution 1080P@30fps
Power Supply DC 12 ± 1V
Power Consumption 120mA(IR Off)；330mA(IR On)
ICR Support
Format 25FPS / 30FPS / PAL / NT
Audio TVI support
S/N Ratio ≧58dB
White Balance Auto
Gain Control Auto
Gamma correction Auto
Day Night Auto Switch Support
LEDs 4 PCS
IR Range 30M
IR Wavelength 850nm
Minimum Illumination 0.1Lux
OUTPUT AHD or CVBS or TVI or CVI
(Default setting: AHD Mode)
Language English / Simplified Chinese / Traditional Chinese
IP Rating IP66
Operating Temperature -20℃~50℃
Dimensions (H×W×D) 190mm x 71mm x 59mm
 Weight About 310g
