| Ssystem |
Flash：256MB |
| RAM：512MB |
| Sensor |
Full HD High Quality 1/2.8” SONY CMOS Image Sensor |
| Lens |
Vari-focal 3.6~11mm |
| IR-cut |
Removable IR Cut filter |
| Lux |
0 Lux(IR ON) |
| LED |
HI-P 8 LED |
| Compression |
H.265/H.264: 3840x2160 at 30 fps |
| H.265/H.264: 2592x1944 at 30 fps |
| H.265/H.264: 2048x1536 at 30 fps |
| H.265/H2.64: 1920x1080 at 30 fps |
| H.265、H.264 Multi-mode compression (Dual Codec) |
| Multi-mode compression streaming |
| Video Adjustment |
Resolution、Quality and bit rate |
| Time、Date or custom text and it’s position |
| Brightness, Contrast, Saturation and Sharpness |
| AGC、AWB、AES、BLC、WDR |
Electronic Shutter
|
1/2 ~ 1/100,000 Sec |
| Network Interface |
10 /100 Mbps RJ-45 |
| Protocol |
IPv4,TCP/IP, DHCP, HTTP, RTSP,SNTP,DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above |
| Safari, Chrome or Firefox |
| Alarm & Event notification |
Motion Detection |
| E-mail notification or upload file to FTP |
| User |
Max. 8 users for live view simultaneously |
| User Authorization |
| OTA |
OTA for Firmware upgrade |
| I/O Port |
RJ-45, DC12V |
| Power |
DC12V or PoE IEEE802.3af Class 0 (optional) |
| Power Consumption |
3.6W(IR OFF) 、12W(IR ON) |
| Weight |
N.W.：965g |
| Dimension |
315mm x 88mm x 87mm |
| Operating Environments |
0 ~ 45 °C |
| IP Rating |
IP67 |
*If the above specifications are different, please refer to the latest date
