CCTV Surveillance System

CCTV Camera

VCF-5757HD

1080P / Dome / IR

  • DC12V

  • 0.1 LUX

  • 50dB

  • LENS2.8~12MM

  • 30LEDs

  • 25M

  • 58dB

  • 1/3CMOS

  • -20~50°C

Download Catalog

Product Features

  • 1/3" CMOS sensor
  • AHD1080P high video quality transmission,up to 1920x1080 pixels
  • 2.8-12 mm lens.
  • AHD or CVBS or TVI or CVI output switch
Pick Up Element 1/3" CMOS sensor
Video System NTSC/PAL
Image Signal Process Digital Signal Processor
Lens 2.8-12mm
Number Of Pixel 1920 (Horizontal) x 1080(Vertical)
Horizontal Resolution 1080P@30fps
Power Supply DC 12 ± 1V
Power Consumption 120mA(IR Off)；340mA(IR On)
ICR Support
Electronic Shutter Auto
White Balance Auto
Gain Contro Auto
S/N Ratio ≧58dB
Day Night Auto Switch Support
LEDs 30 PCS
IR Range 25M
IR Wavelength 850nm
Minimum Illumination 0.1Lux
OUTPUT AHD or CVBS or TVI or CVI
(Default setting: AHD Mode)
Language English / Simplified Chinese / Traditional Chinese /
Russian / Spanish / French / Polish / Italian /
Portuguese / Japanese / Korean / Greek
Operating Temperature -20℃~50℃
Dimensions (H×W×D) Φ143 × 108mm
 Weight About 970g
