IP Surveillance System

IP Camera

VIN-BS702-E6

5MP / Bullet / H.265

  • DC12V

  • 0.01 LUX

  • P.O.E

  • 1/2.8"CMOS

Download Catalog

Product Features

  • SONY 5 M Pixels 1/2.8" CMOS Sensor with excellent image quality
  • Real time H.265/H.264  compression (Dual Codec)
  • Resolution 2592*1944 @ 30fps
  • Simultaneous Multiple Streams
  • Support ONVIF international standard, best compatibility and integration
Ssystem Flash:256MB
RAM:512MB
Sensor Full HD High Quality 1/2.8” SONY CMOS Image Sensor
Lens Support C/CS Mount lens
IR-cut Removable IR Cut filter
Lux 0.01 Lux(IR ON)
Compression H.265/H.264: 2592x1944 at 30 fps
H.265/H.264: 2560x1440 at 60 fps
H.265/H.264: 2048x1536 at 60 fps
H.265/H2.64: 1920x1080 at 60 fps
Multi-mode compression streaming
Video Adjustment Resolution、Quality and bit rate
Time、Date or custom text and it’s position
Brightness, Contrast, Saturation and Sharpness
AGC、AWB、AES、BLC、WDR
Network Interface 10 /100 Mbps RJ-45
Protocol IPv4,TCP/IP, DHCP, HTTP, RTSP,SNTP,DNS
Browser Microsoft Internet Explorer 6.0 or above
Safari, Chrome or Firefox
Alarm & Event notification Motion Detection
E-mail notification or upload file to FTP
User Max. 8 users for live view simultaneously
User Authorization
OTA OTA for Firmware upgrade
I/O Port RJ-45 Ethernet port / Power input port DC 12V /
Auto Iris / Audio input / output /
Alarm output (2in 1out) / Reset button
Power DC12V or PoE IEEE802.3af Class 0 (optional)
Power Consumption 3.6W(IR OFF)
Weight N.W.:345g
Dimension 152 × 70 × 50 mm
Operating Environments 0 ~ 45 °C
*If the above specifications are different, please refer to the latest date
