| Video System |
Flash：16MB |
| RAM：256MB |
| Sensor |
Full HD High Quality 1/2.8” SONY CMOS Image Sensor |
| Lens |
Vari-focal 2.0mm |
| IR cut |
Removable IR-cut filter for day & night function |
| Low Lux |
0.01 Lux |
| LED |
HI-P 3 IR LED |
| Compression |
H.265+: 2560x1920 at 15fps |
| H.265+: 2048x1536 at 20 fps |
| H.265+: 1920x1080 at 30fps |
| H.265、H.264、JPEG Multi-modecompression (Dual Codec) |
| Support Simultaneous multiple streams |
| Image Settings |
Adjustable image size,quality, and bit rate |
| Time/Date stamp and text caption overlay |
Configurable brightness, contrast, saturation,
sharpness,white balance and exposure |
| Have: AGC、AWB、AES、BLC、WDR Features |
Electronic Shutter
|
1/2 ~ 1/100,000 Sec |
| Networking Interface |
10 /100 Mbps RJ-45 |
| Protocol |
IPv4, TCP/IP, DHCP, HTTP, RTSP, SNTP, DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above |
| Safari, Chrome or Firefox |
| Alarm and Event Management |
Motion Detection |
| Event notification using SMTP or FTP |
| Users |
clients on-line monitoring at the same time
Multi-level user access control with password
protection |
|
| Maintenance |
Supports online firmware upgrade |
| I/O |
RJ-45 Ethernet x 1,DC12V |
| Power |
DC12V or PoE IEEE802.3af Class 0 (optional) |
| Max. Power Consumption |
3.6W(IR OFF)、10W(IR ON) |
| Weight |
N.W.：350g |
| Dimensions |
W:Φ120mm H:70mm |
| Operating Temperature |
0 ~ 45 °C |
