| Ssystem |
Flash：128MB |
| RAM：128MB |
| Sensor |
FullHD High Quality 1/2.5” CMOS Image Sensor |
| Lens |
Board Lens 3.6 mm |
| IR-cut |
Removable IR Cut filter |
| Lux |
0 Lux(IR ON) |
| LED |
HI-POWER LED 4PCS |
| Compression |
H.265+: 2560x1920 at 30fps |
| H.265+: 1920x1080 at 30fps |
| H.265+、H.264、JPEG Multi-mode compression (Dual Codec) |
| Multi-mode compression streaming |
| Video Adjustment |
Resolution、Quality and bit rate |
| Time、Date or custom text and it’s position |
| Brightness, Contrast, Saturation and Sharpness |
| AGC、AWB、AES、BLC、WDR |
Electronic Shutter
|
1/2 ~ 1/100,000 Sec |
| Network Interface |
10 /100 Mbps RJ-45 |
| Protocol |
IPv4,TCP/IP, DHCP, HTTP, RTSP,SNTP,DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above |
| Safari, Chrome or Firefox |
| Alarm & Event notification |
Motion Detection |
| E-mail notification or upload file to FTP |
| User |
Max. 8 users for live view simultaneously |
| User Authorization |
| OTA |
OTA for Firmware upgrade |
| I/O Port |
RJ-45, DC12V |
| Power |
DC12V or PoE IEEE802.3af Class 0 (optional) |
| Power Consumption |
3.6W(IR OFF) 、7W(IR ON) |
| Weight |
N.W.：350g |
| Dimension |
190mm x 71mm x 59 mm |
| Operating Environments |
0 ~ 45 °C |
| IP Rating |
IP66 |
*If the above specifications are different, please refer to the latest date
