Humanoid recognition function
| Number of Humanoid Recognition |
It can recognize 5 sets of human on the monitor screen at the same time. |
| Recognizable Size of Human |
The size of himan figure on video screen needs to be 60*100 pixels or more. |
| Accuracy Settings Adjustments |
The initial default value is 0. According to constraints of installation environment, the recognition strict level setting can be adjusted to avoid misjudgment orrelaxation of recognition. |
| Alarm Zone Settings |
Provide two groups of warning area settings,and irregular frames can be set as the warning area setting.
Humanoid recognition in the warning zone can be set.When the humanoid object touches the warning frame, the humanoid object will be listed and tracked until the humanoid object leaves the warning zone.
It can be used with the alarm setting as a linkage setting. |
| Alarm Response Time |
Configurable I/O alarm output time allows the manager to have reponse tome.
Can setup IO alarm output voltage level high/low (0V~3.3V)for remote siren or gearing alert. |
| Alarm Recognition Video Storage |
You can set up for video storage in the SD card of device itself, or set up a FTP Server to transmit the face recognition results to the server. |
| Micro SD Card Storage in Device |
It supports 256GB Micro SD card for face recognition images storage in the device.
It can carry out face recognition images confirmation on the browser page.
(After enabling snapshot function by the face recognition system, the internal SD card will be formatted and forced to stop live monitoring recording.) |
| Co-development |
Please contact FUHO's sales representative to discuss the development and integration of multiple AI system functions. |
SPECIFICATIONS
| system |
Flash：256MB |
| RAM：512MB |
| Sensor |
SONY FullHD High Quality 1/2.8 CMOS Image Sensor |
| Lens |
Board Lens 3.6 mm |
|
| Optical Filter |
Built-in Magnetic Infrared Filter Switcher |
| Low Illumination |
0 Lux(IR ON) |
| Infrared Light |
24pcs IR LED |
Image Performance |
H.265/H.264: 1920x1080 at 60 fps |
| H.265/H.264: 1280x720 at 60 fps |
| H.265/H.264: 640x480 at 60 fps |
| H.265、H.264Multi-mode compression (Dual Codec) |
| Support simultaneous transmission of multimode video streams |
| Video Adjustment |
Resolution、Quality and bit rate |
Time, date or custom text can be displayed on the image,
and the display position can be set |
| Adjustable brightness, contrast, saturation and sharpness |
| AGC、AWB、AES、BLC、WDR |
| Electronic Shutter |
1/2 ~ 1/100,000 Sec |
| Networking Interface |
10 /100 Mbps,RJ-45 |
| Communication Protocol |
IPv4、TCP/IP、DHCP、HTTP、RTSP、SNTP、DNS |
| browser |
Microsoft Internet Explorer 6.0 or above
Safari, Chrome or Firefox |
| Alarm Notification |
High/Low (0-3.3V) alarm signal can be connected to I/O OUT. |
Human recognition results are captured and transmitted
to FTP or device's micro SD card for image storage. |
| Users |
Up to 8 users can online monitor at the same time.
Hierarchical Management of User Rights. |
|
| Maintenance |
Support online firmware upgrade |
| I/O Port |
RJ-45 Network Connection Port,
Power Input Port DC12V,
Sound Input and Output (BNC-RS485 Output),
Alarm Output |
| Power |
VIN-DS755HA-E4:DC12V
VIN-DS755HEA-E4:
DC12V or Ethernet PoE IEEE802.3af Class 0 (optional) |
| Power Consumption |
3.6W(IR OFF) 、12W(IR ON) |
| Weight |
N.W. :1050g |
| Dimension |
W:Φ135mm H:110mm |
| Operating Environments |
0℃ ~ 45℃ |
*Version updating is not going to inform, please check the on-going updating information
