| Video System |
Flash：16MB |
| RAM：128MB |
| Sensor |
FullHD High Quality 1/3” CMOS Image Sensor |
| Lens |
Board Lens 3.6 mm |
| IR cut |
Removable IR Cut filter |
| Lux |
0 Lux(IR ON) |
| IR LED |
HI-P 4 IR LED |
| Compression |
H.265+: 1920x1080 at 30 fps |
| H.265+: 1280x720 at 30 fps |
| H.265+: 640x480 at 30 fps |
| Multi-mode compression streaming |
| Video Adjustment |
Resolution、Quality and bit rate |
| Time、Date or custom text and it’s position |
| Brightness, Contrast, Saturation and Sharpness |
| AGC、AWB、AES、BLC、WDR |
| Networking Interface |
10 /100 Mbps RJ-45 |
| Protocol |
IPv4, TCP/IP, DHCP, HTTP, RTSP, SNTP, DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above |
| Safari, Chrome or Firefox |
| Alarm and Event Management |
Motion Detection |
| E-mail notification or upload file to FTP |
| Users |
Max. 8 users for live view simultaneously |
| User Authorization |
| OTA |
OTA for Firmware upgrade |
| I/O Port |
RJ-45 , DC12V |
| Power |
DC12V or PoE IEEE802.3af Class 0 |
| Power Consumption |
3.6W(IR OFF)、7W(IR ON) |
| IP Rating |
IP66 |
| Weight |
N.W. : 285 g |
| Dimensions |
Φ 110 x 95 mm |
| Operating Temperature |
0 ~ 45 °C |
*If the above specifications are different, please refer to the latest date
