IP Surveillance System

IP Camera

VIN-DJ752HE-F7

5MP / Dome / IR / H.265+ / AI Human Recognition

  • DC12V

  • LENS 3.6mm

  • 30M

  • 0 LUX

  • P.O.E

  • 8 LEDs

  • H.265+

  • CMOS 1/2.5"

Download Catalog

Product Features

  • 5M Pixels 1/2.5" CMOS Sensor with excellent image quality
  • AI intelligent humanoid detection function replaces traditional displacement detection system
  • Real time H.265+/H.264/MJPEG Multi-Mode compression (Dual Codec)
  • Resolution 2560*1920 @ 30 fps/s
  • HI-P 8pcs IR LED, IR Distance 30M
  • Support ONVIF international standard, best compatibility and integration
Video System Flash：128MB
RAM：128MB
Sensor FullHD High Quality 1/2.5” CMOS Image Sensor
Lens Board Lens 3.6 mm
IR cut Removable IR Cut filter
Low Lux 0 Lux(IR ON)
IR LED HI-P 8pcs IR LED
Compression H.265+: 2560x1920 at 30 fps
H.265+: 1920x1080 at 30fps
H.265+、H.264 Multi-mode compression (Dual Codec)
Multi-mode compression streaming
Video Adjustment Resolution、Quality and bit rate
Time、Date or custom text and it’s position
Brightness, Contrast, Saturation and Sharpness
AGC、AWB、AES、BLC、WDR
Networking Interface 10 /100 Mbps RJ-45
Protocol IPv4, TCP/IP, DHCP, HTTP, RTSP, SNTP, DNS
Browser Microsoft Internet Explorer 6.0 or above
Safari, Chrome or Firefox
Alarm and Event Management Motion Detection
E-mail notification or upload file to FTP
Users Max. 8 users for live view simultaneously
User Authorization
OTA OTA for Firmware upgrade
I/O RJ-45 , DC12V
Power DC12V or PoE IEEE802.3af Class 0
Power Consumption 3.6W(IR OFF)、12W(IR ON)
Weight N.W.：630g
Dimensions W:Φ120mm H:85mm
Operating Temperature 0 ~ 45 °C
