Pick Up Element
|
1/3" CMOS sensor
|
|
Video System
|
NTSC / PAL
|
|
Image Signal Process
|
Digital Signal Processor
|
|
Lens
|
2.8mm / 3.6mm
|
|
Number Of Pixel
|
1920(Horizontal) x 1080(Vertical)
|
|
Horizontal Resolution
|
1080P@30fps
|
|
Power Supply
|
DC 12 ± 1V
|
|
Power Consumption
|
120mA (IR Off)；300mA (IR On)
|
|
ICR
|
Support
|
|
Electronic Shutter
|
AUTO
|
|
White Balance
|
Auto
|
|
Gain Control
|
Auto
|
|
S/N Ratio
|
≥50dB
|
|
Day Night Auto Switch
|
Support
|
|
LEDs
|
12 PCS
|
|
IR Range
|
3~5M
|
|
IR Wavelength
|
850nm
|
|
Minimum Illumination
|
0 Lux
|
|
OUTPUT
|
AHD or CVBS or TVI or CVI
(Default setting: AHD Mode)
|
|
Language
|
English / Simplified Chinese / Traditional Chinese / Russian / Italian /Greek
|
|
IP Rating
|
IP68
|
|
Operating Temperature
|
-20℃~50℃
|
|
Dimensions (H×W×D)
|
Ø:60.5mm x 58mm
|
|
Weight
|
About 300g
|
Simliar Product
| Update Date 2021/12/07 |
VCF-5526HD5 |
VCN-S5926HD5 |
| Resolution |
1080P |
| Pick Up Element |
1/3" CMOS |
1/2.8" CMOS |
| LENS/td> |
3.6mm |
2.8mm / 3.6mm |
| LEDS |
12 PCS |
| IR |
✓ |
| IR Wavelength |
850nm |
| IR Range |
3~5M |
| Sensitivity |
0.1Lux |
0.01Lux |
| Starlight Color |
|
• |
| OUTPUT |
AHD、TVI、CVI、CVBS |
| Waterproof |
IP68 |
IP66 |
*If the above specifications are different, please refer to the latest date
