CCTV Surveillance System

CCTV Camera

VCF-5758D

2MP / Dome / IR

  • DC12V

  • LENS 2.0mm

  • 15m

  • 0 LUX

  • 50dB

  • LENS2.8~12MM

  • 25M

  • 58dB

  • 1/3CMOS

  • -20~50°C

  • 3 LEDs

Download Catalog

Product Features

  • 1/3" CMOS sensor
  • AHD 1080P high video quality transmission,up to 1920x1080 pixels
  • View Angle: 2.0 mm
  • AHD, CVBS, TVI or CVI output switch
Pick Up Element 1/3" CMOS sensor
Video System NTSC/PAL
Image signal processing system Digital signal processing system
Lens 2.0 mm
Number Of Pixel 1920 (Horizontal) x 1080(Vertical)
Horizontal Resolution 1080P@30fps
Power Supply DC 12 ± 1V
Power Consumption 120mA(IR Off)；340mA(IR On)
ICR Support
Electronic Shutter Auto
White Balance Auto
Auto Gain Control Auto
S/N Ratio ≧ 50 dB
Day and Night Conversion Support
Number of LED Indicators 3 PCS
IR Range 15M
IR Wavelength 850nm
Minimum Illumination 0 Lux (IR ON)
OUTPUT AHD or CVBS or TVI or CVI
(Factory Reset: AHD)
Language English / Simplified Chinese / Traditional Chinese / Russian / Spanish / French / Polish / Italian / Portugues / Japanese / Korean / Greek
Operating Temperature -20℃~50℃
Dimensions (H×W×D) Φ :150mm x 70mm
 Weight Apx. 310
Version updating is not going to inform, please check the on-going updating information
