Humanoid Recognition Function
| Number of Humanoid Recognition |
It can recognize 5 sets of human on the monitor screen at the same time. |
| Recognizable Size of Human |
The size of human figure on video screen needs to be 60*100 pixels or more. |
| Accuracy Settings Adjustments |
The initial default value is 0. According to constraints of installation environment,
the recognition strict level setting can be adjusted to avoid misjudgment or relaxation of recognition.
Reduce the rate of false positives for human recognition. |
| Alert Zone Settings |
Provide two groups of warning area settings, and irregular frames can be set as the warning area setting.
Humanoid recognition in the warning zone can be set.
When the humanoid object touches the warning frame,the humanoid object will be listed
and tracked until the humanoid object leaves the warning zone.
It can be used with the alarm setting as a linkage setting. |
| Alert Response Time |
Configurable I/O alarm output time allows the manager to have response time.
Can setup IO alarm output voltage level high/low (0V~3.3V) for remote siren or gearing alert. |
Humanoid recognition
image storage |
You can set up for video storage in the SD card of device itself,
or set up a FTP Server to transmit the humanoid recognition results to the server. |
| Micro SD Card Storage in Device |
It supports 256 GB Micro SD card for humanoid recognition images storage in the device.
It can carry out humanoid recognition images confirmation on the browser page.
(After the humanoid recognition system captures SD card photo function is turned on,
the built-in SD card will be formatted and forcibly turn off normal surveillance video) |
| Co-development |
Please contact FUHO sales representative to discuss the
development and integration of multiple AI system functions. |
SPECIFICATIONS
| system |
Flash：256MB |
| RAM：512MB |
| Image Sensor |
SONY FullHD High Quality 1/2.8 CMOS Image Sensor |
| Lens |
3.6mm |
|
| Optical Filter |
Built-in Magnetic Infrared Filter Switcher |
| Low Lux |
0 Lux |
| Number of LED |
2 High Power IR LEDS |
| Image |
H.265/H.264: 1920x1080 at 60 fps |
| H.265/H.264: 1280x720 at 60 fps |
| H.265/H.264: 640x480 at 60 fps |
| H.265、H.264 JPEG Multi-mode compression (Dual Codec) |
| Support Simultaneous multiple streams |
| Image Adjustment |
Adjustable image size,quality, and bit rate |
Time, date or custom text can be displayed on the image,
and the display position can be set |
| Adjustable brightness, contrast, saturation and sharpness |
| Support AGC、AWB、AES、BLC、WDR Features |
| Electronic Shutter |
1/2 ~ 1/100,000 Sec |
| Networking Interface |
10/100 Mbps Ethernet, RJ-45 |
| Communication Protocol |
IPv4、TCP/IP、DHCP、HTTP、RTSP、SNTP、DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above
Safari, Chrome or Firefox |
| Alarm and Event Management |
Abnormal Motion Detection Mode |
| Event notification using SMTP or FTP |
| Users |
8 clients online monitoring simultaneously |
| Multi-level user access control with password protection |
| Maintenance |
Supports FOTA |
| I/O Port |
RJ-45 network port, power input port DC12V |
| Power |
DC12V |
| Max. Power Consumption |
3.6W(IR OFF)、12W(IR ON) |
| Weight |
N.W. :380g |
| Dimension |
62mm x 89mm x 74mm |
| Working Environment |
0℃ ~ 45℃ |
| Waterproof and Dustproof Level |
IP67 |
