IP Surveillance System

IP Camera

VIN-US713C-EA

1080P / IP67 / IR / H.265 / LPR

  • H.265

  • DC12V

  • LENS 3.6mm

  • 15M

  • 0 LUX

  • 1/2.8"CMOS

  • 0~45°C

  • ANPR

  • 2 LEDS

Download Catalog

Product Features

  • The camera is equipped with built-in AI algorithms that can accurately recognize
    human-shaped objects.
  • Starlight-grade Sony CMOS low lux color image with high resolution to
    enhanced night-time surveillance.
  • Real-time H.265/H.264 multi-mode engine compression technology (Dual Codec) supports
    multiple levels of video quality configuration.
  • Resolution up to 1920x1080 at 60 fps.
  • 2 High Power IR LEDS, IR Range 15 M
  • The identification results are linked with the Vacron recording system to grasp the monitoring
    and alarm information in real time.
  • Support ONVIF international standard with best compatibility and integration, the SDK can
    be attached for the back-end system vendor's integrations.


Licence plate recognition feature

License plate recognition quantity license plate recognition on CCTV monitor at the same time.
License plate recognition size 120 x 80 pixel license plate image required.
License plate recognition mode Can setup on or off and white list setup for accessible vehicle or alert vehicle control.
Accuracy
configuration adjustment		 Default low according to installation environment limit recognition rigorous level adjustable for best accuracy.
License plate alert notification Connected with IO output high/low w(3.3V~0) alarm signal.
Recognition images uploaded to FTP or saved in micro SD card.
Alert response time IO alarm time adjustable for security forces time management.
Can setup IO alarm output voltage level high/low (3.3V~0) for remote
siren or gearing alert.
License plate
recognition image storage		 SD card storage and FTP upload are alternative.
30 seconds an image in condition of same license plate for saving storage and whole system stability.
Control list setup Up to 10,000 license plate data control
Micro SD card storage Micro SD card 256 GB support for license plate recognition images storage and verification on browser available. SD card will be formatted and normal recording off when license plate recognition system snapshot function activated.
Cooperative development Please contact sales for various AI powered system integration and cooperative development


SPECIFICATIONS

system Flash：256MB
RAM：512MB
Image Sensor SONY FullHD High Quality 1/2.8” CMOS Image Sensor
Lens 3.6mm
Optical Filter Built-in Magnetic Infrared Filter Switcher
Low Lux 0 Lux
Number of LED  2 High Power IR LEDS
Image H.265/H.264: 1920x1080 at 60 fps
H.265/H.264: 1280x720 at 60 fps
H.265/H.264: 640x480 at 60 fps
H.265、H.264 JPEG Multi-mode compression (Dual Codec)
Support Simultaneous multiple streams
Image Adjustment Adjustable image size,quality, and bit rate
Time, date or custom text can be displayed on the image,
and the display position can be set
Adjustable brightness, contrast, saturation and sharpness
Support AGC、AWB、AES、BLC、WDR Features
Electronic Shutter 1/2 ~ 1/100,000 Sec
Networking Interface 10/100 Mbps Ethernet, RJ-45
Communication Protocol IPv4、TCP/IP、DHCP、HTTP、RTSP、SNTP、DNS
Browser Microsoft Internet Explorer 6.0 or above
Safari, Chrome or Firefox
Alarm and Event Management  Abnormal Motion Detection Mode
 Event notification using SMTP or FTP
Users 8 clients online monitoring simultaneously
Multi-level user access control with password protection
Maintenance Supports FOTA
I/O Port RJ-45 network port, power input port DC12V
Power DC12V
Max. Power Consumption 3.6W(IR OFF)、12W(IR ON)
Weight N.W. :380g
Dimension 62mm x 89mm x 74mm
Working Environment 0℃ ~ 45℃
Waterproof and Dustproof Level IP67
