| system |
Flash：128MB |
| RAM：128MB |
| Image Sensor |
FullHD High Quality 1/2.5” CMOS Image Sensor |
| Lens |
2.8-12mm |
|
| ICR |
Removable IR-cut filter for day & night function |
| Low Lux |
0 Lux |
| Number of LED |
High Power IR LEDs x12 |
| Image performance |
H.265: 2560x1920 at 30 fps |
| H.265: 1920x1080 at 30 fps |
| H.265、H.264、JPEG Multi-mode compression (Dual Codec) |
| Support Simultaneous multiple streams |
| Image Adjustment |
Adjustable image size, quality, and bit rate |
| Time/Date stamp and text caption overlay |
| Configurable brightness, contrast, saturation, sharpness, white balance, and exposure |
| Support AGC、AWB、AES、BLC、WDR Features |
| Electronic Shutter |
1/2 ~ 1/100,000 Sec |
| Networking Interface |
10/100 Mbps Ethernet, RJ-45 |
| Communication Protocol |
IPv4、TCP/IP、DHCP、HTTP、RTSP、SNTP、DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above
Safari, Chrome or Firefox
|
| Alarm and Event Management |
Abnormal Detection
Notify via email or upload files to FTP
|
| Users |
8 clients online monitoring simultaneously |
| Multi-level users access control with password protection |
| Maintenance |
Supports FOTA |
| I/O Port |
RJ-45 network port, power input port DC12V |
| Power |
DC12V |
| Max. Power Consumption |
3.6W(IR OFF)、18W(IR ON) |
| Weight |
Net weight : 1170g |
| Dimension |
255mm x 75.3mm x 75mm |
| Working Environment |
0℃ ~ 45℃ |
| Waterproof and Dustproof Level |
IP66 |
