| System |
Flash：16MB |
| RAM：256MB |
| Image Sensor |
FullHD High Quality 1/2.8” SONY CMOS Image Sensor |
| Lens |
Motorized / Automatic Zoom 5~50mm |
| ICR |
Built-in Magnetic Infrared Filter Switch |
| Low Lux |
0 Lux (IR ON) |
| Number of LED |
High Power IR LEDs x12 |
| Image |
H.265+: 2560x1920 at 15 fps |
| H.265+: 2048x1536 at 20 fps |
| H.265+: 1920x1080 at 30 fps |
| H.265+, H.264, JPEG Multi-mode compression (Dual Codec) |
| Support Simultaneous multiple streams |
| Image Adjustment |
Adjustable image size, quality, and bit rate
Time/Date stamp and text caption overlay
Configurable brightness, contrast, saturation, sharpness, white balance and exposure
Have: AGC、 AWB、 AES、 BLC、 WDR Features |
| Network Interface |
10 /100 Mbps,RJ-45 |
| Communication Protocol |
IPv4,TCP/IP, DHCP, HTTP, RTSP,SNTP,DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above |
| Safari, Chrome or Firefox |
| Alarm and Event Management |
Abnormal Detection |
| Notify via email or upload files to FTP |
| Users |
8 clients online monitoring simultaneously |
| Multi-level users access control with password protection |
| Maintenance |
Supports FOTA |
| I/O |
RJ-45 network port, power input DC12V |
| Power |
DC12V |
| Max. Power Consumption |
3.6W(IR OFF), 18W(IR ON) |
| Weight |
Net weight: 1235g |
| Dimension (WxDxH) |
315.5 x 147 x 116 mm |
| Operating Temperature |
0 ~ 45 °C |
| IP Rating |
IP66 |
Version updating is not going to inform, please check the on-going updating information
