| System |
Flash：256MB |
| RAM：512MB |
| Image Sensor |
SONY FullHD High Quality 1/2.8” CMOS Image Sensor |
| Lens |
Motorized / Automatic Zoom 2.8~12mm |
|
| ICR |
Built-in Magnetic Infrared Filter Switch |
| Low Lux |
0 Lux (IR ON) |
| Number of LED |
High Power IR LEDs x8 |
Image |
H.265/H.264: 3840x2160 at 30 fps |
| H.265/H.264: 3072x2048 at 30 fps |
| H.265/H.264: 2592x1944 at 30 fps |
| H.265/H.264: 2560x1440 at 30 fps |
| H.265/H.264: 2048x1536 at 30 fps |
| H.265/H.264: 1920x1080 at 30 fps |
| H.265/H.264: 1280x720 at 30 fps |
| H.265, H.264 multi-mode engine compression technology (Dual Codec) |
| Support Simultaneous multiple streams |
| Image Adjustment |
Adjustable image size, quality, and bit rate |
| Time, date, or custom text can be displayed on the image, and the display position can be set. |
| Adjustable brightness, contrast, saturation, and sharpness |
| Support AGC、 AWB、 AES、 BLC、 WDR Features |
| Electronic Shutter |
1/2 ~ 1/100,000 Sec |
| Network Interface |
10/100 Mbps Ethernet, RJ-45 |
| Communication Protocol |
IPv4、 TCP/IP、 DHCP、 HTTP、 RTSP、 SNTP、 DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above
Safari, Chrome or Firefox |
| Alarm and Event Management |
Abnormal Detection |
| Notify via email or upload files to FTP |
| Users |
8 clients online monitoring simultaneously
Multi-level users access control with password protection |
|
| Maintenance |
Supports FOTA |
| I/O |
RJ-45 network port, power input DC12V |
| Power |
DC12V or Ethernet PoE IEEE802.3af Class 0 (optional) |
| Max. Power Consumption |
3.6W(IR OFF), 10W(IR ON) |
| Weight |
Net weight: 600g |
| Dimension (WxDxH) |
255mm x 75.3mm x 75mm |
| Operating Environments |
0℃ ~ 45℃ |
| IP Rating |
IP66 |
