SPECIFICATIONS
| system |
Flash：256MB |
| RAM：512MB |
| Sensor |
SONY FullHD High Quality 1/2.8 CMOS Image Sensor |
| Lens |
Board Lens 3.6 mm |
|
| IR Cut |
Removable IR Cut filte |
| Lux |
0 Lux (IR ON) |
| IR LED |
HI-P 8pcs IR LED |
Image Performance |
H.265: 2592x1944 at 30fpss |
| H.265: 2560x1440 at 60fps |
| H.265: 2048x1536 at 60fps |
| H.265: 1920x1080 at 60fps |
| H.265、H.264 Multi-mode compression (Dual Codec) |
| Multi-mode compression streaming |
| Video Adjustment |
Resolution、Quality and bit rate |
Time, date or custom text can be displayed on the image,
and the display position can be set |
| Adjustable brightness, contrast, saturation and sharpness |
| AGC、AWB、AES、BLC、WDR |
| Network Interface |
10 /100 Mbps,RJ-45 |
| Protocol |
IPv4、TCP/IP、DHCP、HTTP、RTSP、SNTP、DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above
Safari, Chrome or Firefox |
| Alarm & Event notification |
Motion Detection |
| E-mail notification or upload file to FTP |
| Users |
Max. 8 users for live view simultaneously
User Authorization
|
|
| OTA |
OTA for Firmware upgrade |
| I/O Port |
RJ-45, DC12V, Audio in |
| Power |
DC12V or PoE IEEE802.3af Class 0 (optional) |
| Power Consumption |
3.6W(IR OFF) 、12W(IR ON) |
| Weight |
Net Weight: 690g |
| Dimension |
W:Φ120mm H:85mm |
| Operating Environments |
0℃ ~ 45℃ |
*Version updating is not going to inform, please check the on-going updating information
