IP Surveillance System

NVR

VDN-NKF808EE

8CH / 5MP / H.265

  • H.265

  • Motion

  • LAN

  • P.O.E

  • USB

  • CMS

  • GUI

  • Mouse

  • Users

  • SATA

  • Multi Function

Download Catalog

Product Features

  • Equipped with POE Switch(8CH).
  • Multitasking: which can Record / Playback / Remote Connection / Mobile phone watch and playback at the same time.
  • The maximum supporting capacity for a single hard disk is 10 TB.
  • Support HD ultra high definition output.
  • It supports remote IE browsing, monitors live footage, and provides playback simultaneously.
  • Provide HTTP, DHCP, DDNS, NTP, SMTP, FTP, DNS, UPNP, PPPoE, IP authority services.
  • Support iPhone, Android video monitoring and playback.
  • It supports CMS (Central Management System).
  • With P2P function, scan the QR-Code through APP for real-time monitoring and playback to increase information security.
  • Set the IP CAM mode on the host, and use FUHO IP Cam to plug and play.
  • Support automatic updates.
Video Input 8CH 5MP (RJ45 input)
Video Output VGA (Maximum 1920x1080)
HD OUT output (Max. 3840 x 2160)
Audio Compression G.711U
Digital Zoom in YES
Auto Sequence Duration YES
Video Compression H.264 / H.265
Monitoring VGA @30FPS/sec. up to 8CH Monitoring
1-channel real-time video monitoring in 5MP@15 FPS/sec
Recording Mode Continuous / Schedule / Motion
Motion Detection Grid setting can set up 192 detection zones (16 x 12)
Playback Video playback can reach up to 1 channel 5MP@10 FPS/sec.
or 1 channel 1080P@30 frame/second
or 8 channel VGA@30 frame/second playback
Display Mode Single, Quad, 9-Split, Sequence
Backup File Format MP4 / self-defined format.
Backup File Method USB / Network
Playback YES
Network Services HTTP、 DHCP、 DDNS、 NTP、 SMTP、 FTP、 DNS、 UPNP、 PPPoE、 IP Authority
Network Connection Live View, Search/Playback, Backup, and Update
Browser IE / WEB-Client
HDD Storage Interface SATA x 2
Max. Supported Capacity 10TB per unit
Network Socket RJ-45*1, 10/100/1000 Base-T
USB Front plate USB2.0*1 / black plate USB2.0*1
File System Stable and Reliable Self-Developed File System
S. M. A. R. T. Hard Disk Error Check
Operation Menu Graphical User Interface (GUI); Supports simultaneous display on VGA and HD out
Input Method Mouse
Internal Buzzer Beep when activated
Languages English, Simplified Chinese, Traditional Chinese, Japanese
Firmware Update USB update or Network Update(OTA)
APP Monitoring iPhone, Android, Mobile App supports Live view& audio,
playback and back-up.
Central Monitoring Video
Management System (CMS)		 Support
Operating Environment Celsius 0 ~ 46 degrees, humidity 20 ~ 80%
Power Supply  DC48-52V / 4.5A
Net Weight  About 3.5 kg (without HDD)
Dimensions 430mm x 314mm x 53mm (L×W×H)
*Version updating is not going to inform, please check the on-going updating information
