| Video Input |
16CH 5MP |
| Video Output |
VGA (Max. 1920x1080)
HD (Max. 3840×2160) |
| Sound Compression |
G.711U |
| Digital Zoom in |
YES |
| Sequencing |
YES |
| Image Decoding Methods |
H.264 / H.265 |
| Recording Frame |
VGA @30FPS/sec. up to 16 CH Monitoring
1-channel real-time video monitoring in 5MP@10 FPS/sec. |
| Recording Mode |
Continuous, scheduled, displacement |
| Motion Detection |
Zones: 192(16×12 grid). |
| Playback |
Video playback up to 1 channel 5MP@10 frames per second,
or 1 channel 1080P@30 FPS/sec,
or 16 channel VGA@30 FPS/sec. |
| Display Mode |
Single, Quad, 9-Split, 16-Split, Sequence |
| Backup File Format |
MP4 / Self-Defined Format |
| Backup File Method |
USB/ WEB |
| Network Services |
HTTP, DHCP, DDNS, NTP, SMTP, FTP, DNS, UPNP, PPPoE, IP authority |
| Network Connection |
Live View Search/Playback, Backup, and Update |
| Browser |
IE / WEB-Client |
| HDD Storage Interface |
SATA x 4 |
| Maximum Supported Capacity |
10TB per unit |
| Network Socket |
RJ-45*1 (10/100/1000 Base-T) |
| USB |
Front plate USB2.0x1 / Back plate USB2.0x1 |
| File System |
Stable and Reliable Self-Developed File System |
| S. M. A. R. T. |
Hard Disk Error Check |
| Operation Menu |
GUI interface；VGA & HD out simultaneously |
| Input Method |
Mouse |
| Internal Buzzer |
Start-up Beep |
| Languages |
English, Simplified Chinese, Traditional Chinese, Japanese |
| Firmware Update |
USB update or Network Update(OTA) |
| APP Monitoring |
iPhone, Android, Mobile App supports Live view& audio, playback and back-up |
Central Monitoring Video
Management System (CMS) |
Supports |
| Operating Environment |
Temperature 0~+46ºC, Humidity: 20~80% |
| Power |
DC 12V / 6A (AC100V~240V 50/60HZ) |
| Net Weight (Gross Weight) |
Approx. 4.2kg (without HDD & Power Adapter) |
| Dimensions |
430mm×370mm×120mm (L×W×H) |
