SPECIFICATIONS
| system |
Flash：256MB |
| RAM：512MB |
| Image Sensor |
Full HD High Quality 1/2.8” SONY CMOS Image Sensor |
| Lens |
Varifocal 3.6~11mm |
|
| ICR |
Removable IR Cut filter |
|
| Low Lux |
0 Lux(IR ON) |
| Number of LED |
24pcs IR LED |
Image |
H.265/H.264: 3840x2160 at 30 fps |
| H.265/H.264: 3072x2048 at 30 fps |
| H.265/H.264: 2592x1944 at 30 fps |
| H.265/H.264: 2560x1440 at 30 fps |
| H.265/H.264: 2048x1536 at 30 fps |
| H.265、 H.264 Multi-mode compression (Dual Codec) |
| Multi-mode compression streaming |
| Image Adjustment |
Resolution、Quality and bit rate |
| Time、 Date or custom text and it’s position |
| Brightness, Contrast, Saturation and Sharpness |
| AGC、AWB、AES、BLC、WDR |
| Electronic Shutter |
1/2 ~ 1/100,000 Sec |
| Networking Interface |
10 /100 Mbps,RJ-45 |
| Communication Protocol |
IPv4、TCP/IP、DHCP、HTTP、RTSP、SNTP、DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above
Safari, Chrome or Firefox |
| Alarm and Event Management |
Motion Detection |
| E-mail notification or upload file to FTP |
| Users |
Max. 8 users for live view simultaneously
User Authorization
|
|
| Maintenance |
OTA for Firmware upgrade |
| I/O Port |
RJ-45, DC12V |
| Power |
DC12V or PoE IEEE802.3af Class 0 (optional) |
| Max. Power Consumption |
3.6W(IR OFF) 、10W(IR ON) |
| Weight |
Net Weight: 690g |
| Dimension |
W:Φ135mm H:110mm |
| Operating Environments |
0℃ ~ 45℃ |
*Version updating is not going to inform, please check the on-going updating information
