| System |
Flash：16MB |
| RAM：128MB |
| Image Sensor |
FullHD High Quality 1/3” CMOS Image Sensor |
| Lens |
3.6 mm |
| ICR |
Built-in Magnetic Infrared Filter Switch |
| Minimum Illumination |
0 Lux(IR ON) |
| Number of LED Indicators |
High Power IR LEDS x6 |
| Image |
H.265+: 1920x1080 at 30 fps |
| H.265+: 1280x720 at 30 fps |
| H.265+: 640x480 at 30 fps |
| H.265+, H.264, JPEG Multi-mode compression (Dual Codec) |
| Support Simultaneous multiple streams |
| Image Adjustment |
Adjustable Image Size, Quality and Transmission Speed |
| Time, date, or custom text can be displayed on the image and the display position can be set. |
| Adjustable brightness, contrast, saturation and sharpness |
| Support AGC, AWB, AES, BLC, WDR Features |
| Electronic Shutter |
1/2 ~ 1/100,000 Sec |
| Networking Interface |
10 /100 Mbps RJ-45 |
| Protocol |
IPv4, TCP/IP, DHCP, HTTP, RTSP, SNTP, DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above |
| Safari, Chrome or Firefox |
| Alarm and Event Management |
Motion Detection |
| Notify via E-mail or upload files to FTP |
| Users |
8 clients online monitoring simultaneously |
| Multi-level user access control with password protection |
| Maintenance |
Supports FOTA |
| I/O |
RJ-45 Ethernet x1, DC 12V Jack x1 |
| Power |
DC12V or PoE IEEE802.3af Class 0 (optional) |
| Max. Power Consumption |
3.6W(IR OFF), 7W(IR ON) |
| Weight |
Net weight: 344 g |
| Dimensions |
172mm x 70mm x 70mm |
| Operating Temperature |
0 ~ 45 °C |
| IP Rating |
IP66 |
