Mobile Surveillance

Dash Cam

VVN-BS042

8CH / 1080P / SDcard / H.265 / GPS

  • H.265

  • G-Sensor

  • Alarm

  • Battery Built-in

  • GPS

  • GUI

  • SD

  • -20~70°C

  • Bonus Rec

Download Catalog

Product Features

  • 7-inch Capacitive Touchscreen with Video Output – Enables direct playback and viewing on the in-vehicle host.
  • Auto Recording on Startup – Begins recording instantly without additional setup for greater convenience.
  • Built-in 3-Axis G-Sensor – Automatically triggers event recording to ensure complete images during incidents.
  • H.265 Video Compression – Delivers higher compression efficiency.
  • Recording Formats: Supports 1080P / 720P / D1 with an intuitive GUI interface.
  • A complete and reliable image record list makes searching for image records more convenient
  • Complete audio and image recording while driving in case of accountability when incidents occur.
  • Supports AVI and MP4 file conversion, allowing users to play videos directly on standard home computers.
    ps. Please download Carbox Player from the official website to perform the operation.
  • Features power management with delayed shutdown after ignition off (60 seconds max.), enabling
    continuous monitoring functionality.
  • Built-in gold capacitor automatically delay recording when the engine is off, and ensure that data is
    written back to the memory card.
  • Simple and user-friendly interface and icon.
  • The GPS function provides data such as speed, coordinate records and history-routes.(Standard)
SOC NT98332
RAM DDR4 8Gbx2 @1600MHz
Flash NAND Flash 1Gb
Operation System Embedded Linux
Storage SD Cardx1 (Max. 1TB)、SSD (Optional)
AI Performance 0.75T (ADAS+DMS or BSD)
Monitor Dimension High resolution 7" TFT Coloured Monitor
Resolution 1024x600
Recording resolution 1080P15 x 8ch / 720P30 x 8ch
Display Mode  Single Screen / 4-Split / 9-Split
Touchscreen Tempered glass surface + PC material (P+G)
Alarm in  4 sets (Park, Left, Right, Reverse) ON@+24V
Wire Input RCAx1
Wire Output  Connect to AV Host
Camera Power Output S Terminal 12V/3.2A@8CH
Camera Input S Terminal AHD/TVI 720P/1080Px8CH
Video Output Connect to AV Host (AHD 720P30 )
GPS  Exterial G-MOUSE
GSM 4G Module (Quectel EC25-AU) (Optional)
SIM Card Built-in flip-top large card
G-SENSOR Support
Gold Capacitor  Built-in 10F, 5 seconds of delay recoding when black out.
 System Solutions ARM CA7 + Andes N13 + 2D GPU
DDR 1G bits
Flash Memory 2G bits
Support MCU Chipset
Supports Radio Tuner
Support AMP Chipset
4ohm @ 14.4 V、1 kHz、THD 10 %
Monitoring System  The recording will resume once power is restored
Power Input Starting Voltage>DC 18.5
Operating Voltage DC 15V~DC35V
Current  ACC ON 0.8A @24V、ACC OFF 0.003@24V
Operating Temperature -20°C~70°C

All specifications shown are typical unless otherwise stated and are subject to change without notice.
