CCTV Surveillance System

CCTV Camera

VCT-5708H-A

1080P / Bullet / IR

  • DC12V

  • LENS 3.6mm

  • 15m

  • 0 LUX

  • 8 LEDs

  • 58dB

  • 1/3CMOS

  • -20~50°C

Download Catalog

Product Features

  • 1/3" CMOS sensor.
  • 1080P, quality up to 1920x1080.
  • 3.6 mm lens.
  • TVI supports coaxial audio transmission.
  • AHD or CVBS or TVI or CVI output swit ch.

Image Sensor

1/3" CMOS sensor

Signal Mode

NTSC / PAL

Image signal processing system

Digital Signal Processor

Lens

3.6mm

Effective Pixel

1920(Horizontal) x 1080(Vertical)

Resolution

1080P@30fps

Power

DC 12 ± 1V

Power Consumption

120mA (IR Off)；330mA (IR On)

ICR

Support

TV Signal Format

25FPS / 30FPS / PAL / NT

Audio

TVI supports coaxial audio transmission

S/N Ratio

≧58dB

White Balance

Auto

Auto Gain

Auto

Gamma correction

Auto

Day Night Auto Switch

Support

LEDs

High Power IR LEDs x8

IR Range

15 m

IR Wavelength

850nm

Minimum Illumination

0 Lux(IR ON)

OUTPUT

AHD or CVBS or TVI or CVI (Default setting: TVI Mode)

Language

English / Traditional Chinese

Operating Temperature

-20℃~50℃

Dimensions (H×W×D)

85.5mm × 92.8mm × 263.1mm

Weight

About 670g
