| System |
Flash：128MB |
| RAM：128MB |
| Image Sensor |
FullHD High Quality 1/2.5” CMOS Image Sensor |
| Lens |
3.6 mm |
| ICR |
Built-in Magnetic Infrared Filter Switch |
| Minimum Illumination |
0 Lux(IR ON) |
| Number of LED Indicators |
High Power IR LEDS x 4 |
| Image |
H.265/H.264: 2560x1920 at 30 fps |
| H.265/H.264: 1920x1080 at 30 fps |
| H.265 & H.264 Multimode Engine Compression Technology (Dual Codec) |
| Support Simultaneous multiple streams |
| Image Adjustment |
Adjustable Image Size, Quality and Transmission Speed. |
| Time, date, or custom text can be displayed on the image, and the display position can be set. |
| Adjustable Brightness, Contrast, Saturation and Sharpness |
| Support AGC, AWB, AES, BLC, WDR Features |
| Audio output |
2W Speaker (Optional) |
| Electronic Shutter |
1/2 ~ 1/100,000 Sec |
| Networking Interface |
10 /100 Mbps RJ-45 |
| Protocol |
IPv4, TCP/IP, DHCP, HTTP, RTSP, SNTP, DNS |
| Browser |
Microsoft Edge、Google Chrome |
|
| Alarm and Event Management |
Human Detection Alarm
(Alarm Zone setting and Intrusion Alarm setting) |
| Event notification using SMTP or FTP |
| Users |
Maximum 8 users online monitoring simultaneously |
| Multi-level user access control with password protection |
| Maintenance |
Supports FOTA |
| I/O |
RJ-45 network port, power input port DC12V |
| Power |
DC12V |
| Max. Power Consumption |
3.6W(IR OFF) 、10W(IR ON) |
| Weight |
Net weight: 502g |
| Dimensions |
71mm x 70mm x 161mm |
| Operating Temperature |
0 ~ 45 °C |
