| System |
Flash：16MB |
| RAM：128MB |
| Sensor |
FullHD High Quality 1/3” CMOS Image Sensor |
| Lens |
3.6 mm |
| IR Cut |
Built-in Magnetic Infrared Filter Switch |
| Lux |
0 Lux (IR ON) |
| LED |
High Power IR LEDS X 6 |
Compression |
H.265+: 1920x1080 at 30fps |
| H.265+: 1280x720 at 30 fps |
| H.265+: 640x480 at 30fps |
H.265+、H.264、JPEG Multi-mode compression (Dual Codec)
Support Simultaneous multiple streams |
| Image Settings |
Adjustable image size, quality, and bit rate.
Time, date, or custom text can be displayed on the image, and the display position can be set.
Adjustable brightness, contrast, saturation, and sharpness.
Support AGC、AWB、AES、BLC、WDR Features. |
| Electronic Shutter |
1/2 ~ 1/100,000 Sec |
| Network Interface |
10/100 Mbps Ethernet, RJ-45 |
| Protocol |
IPv4,TCP/IP, DHCP, HTTP, RTSP,SNTP,DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above
Safari, Chrome or Firefox |
| Alarm & Event notification |
Abnormal Motion Detection |
| Notify via email or upload files to FTP. |
| User |
8 clients online monitoring simultaneously. |
| Multi-level user access control with password protection. |
| OTA |
Supports FOTA |
| I/O |
RJ-45 network port, power input port DC12V |
| Power |
DC12V or PoE IEEE802.3af Class 0(Optional) |
| Power Consumption |
3.6W(IR OFF) 、10W(IR ON) |
| Operating Environments |
0 ~ 45 °C |
| Weight |
Net weight: 450g |
| Dimensions |
Ø 70.3mm x 103mm |
*If the above specifications are different, please refer to the latest date
