| System |
Flash：128MB |
| RAM：128MB |
| Image Sensor |
FullHD High Quality 1/2.5” CMOS Image Sensor |
| Lens |
3.6 mm |
| ICR |
Built-in Magnetic Infrared Filter Switch |
| Minimum Illumination |
0 Lux(IR ON) |
| Number of LED Indicators |
High Power IR LEDS x 8 |
| Image |
H.265/H.264: 2560x1920 at 30 fps |
| H.265/H.264: 1920x1080 at 30 fps |
H.265、H.264、JPEG Multi-mode compression
(Dual Codec) |
| Support Simultaneous multiple streams |
| Image Adjustment |
Adjustable image size, quality, and bit rate. |
| Time/Date stamp and text caption overlay |
| Adjustable brightness, contrast, saturation, and sharpness. |
| Support AGC, AWB, AES, BLC, WDR Features |
| Electronic Shutter |
1/2 ~ 1/100,000 Sec |
| Networking Interface |
10/100 Mbps Ethernet, RJ-45 |
| Protocol |
IPv4, TCP/IP, DHCP, HTTP, RTSP, SNTP, DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above |
| Safari, Chrome or Firefox |
| Alarm and Event Management |
Human Detection Alarm
(Alarm Zone setting and Intrusion Alarm setting)
|
| Notify via E-mail or upload files to FTP |
| Users |
8 clients online monitoring simultaneously |
Multi-level user access control with password
protection. |
| Maintenance |
Supports FOTA
|
| I/O |
RJ-45 network port, power input port DC12V |
| Power |
DC12V or PoE IEEE802.3af Class 0 |
| Max. Power Consumption |
3.6W(IR OFF), 18W(IR ON) |
| Operating Temperature |
0℃ ~ 45℃ |
| Weight |
Net weight: 670 g |
| Dimensions |
262mm x 91mm x 83mm |
