| System |
Flash：128MB |
| RAM：128MB |
| Sensor |
FullHD High Quality 1/2.5” CMOS Image Sensor |
| Lens |
3.6 mm |
| IR Cut |
Built-in Magnetic Infrared Filter Switch |
| Lux |
0 Lux (IR ON) |
| LED |
High Power IR LEDS X 6 |
Compression |
H.265/H.264: 2560x1920 at 30 fps |
| H.265/H.264: 1920x1080 at 30 fps |
H.265、H.264、JPEG Multi-mode compression
(Dual Codec)
Support Simultaneous multiple streams |
| Image Settings |
Adjustable image size, quality, and bit rate.
Time/Date stamp and text caption overlay
Adjustable brightness, contrast, saturation, and sharpness.
Support AGC、AWB、AES、BLC、WDR Features. |
| Electronic Shutter |
1/2 ~ 1/100,000 Sec |
| Network Interface |
10/100 Mbps Ethernet, RJ-45 |
| Protocol |
IPv4, TCP/IP, DHCP, HTTP, RTSP, SNTP, DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above
Safari, Chrome or Firefox |
| Alarm & Event notification |
Human Detection Alarm
(Alarm Zone setting and Intrusion Alarm setting)
|
| Notify via email or upload files to FTP. |
| User |
8 clients online monitoring simultaneously. |
| Multi-level user access control with password protection. |
| OTA |
Supports FOTA |
| I/O |
RJ-45 network port, power input port DC12V |
| Power |
DC12V or PoE IEEE802.3af Class 0(Optional) |
| Power Consumption |
3.6W(IR OFF) 、10W(IR ON) |
| Operating Environments |
0 ~ 45 °C |
| Weight |
Net weight: 405g |
| Dimensions |
Ø 70.3mm x 103mm |
*If the above specifications are different, please refer to the latest date
