| System |
Flash：16MB |
| RAM：128MB |
| Sensor |
FullHD High Quality 1/3” CMOS Image Sensor |
| Lens |
Board Lens 3.6 mm |
| IR Cut |
Removable IR Cut filter |
| Lux |
0 Lux (IR ON) |
| LED |
High Power IR LEDS X 4 |
Compression |
H.265+: 1920x1080 at 30fps |
| H.265+: 1280x720 at 30 fps |
| H.265+: 640x480 at 30fps |
H.265+、H.264、JPEG Multi-mode compression (Dual Codec)
Support Simultaneous multiple streams |
| Video Adjustment |
Resolution、Quality and bit rate
Time、Date or custom text and it’s position
Brightness, Contrast, Saturation and Sharpness
AGC、AWB、AES、BLC、WDR |
| Network Interface |
10/100 Mbps Ethernet, RJ-45 |
| Protocol |
IPv4,TCP/IP, DHCP, HTTP, RTSP,SNTP,DNS |
| Browser |
Microsoft Internet Explorer 6.0 or above
Safari, Chrome or Firefox |
| Alarm & Event notification |
Motion Detection |
| E-mail notification or upload file to FTP |
| User |
8 clients online monitoring simultaneously. |
| Multi-level user access control with password protection. |
| OTA |
OTA for Firmware upgrade |
| I/O Port |
RJ-45, DC12V |
| Power |
DC12V or PoE IEEE802.3af Class 0 |
| Power Consumption |
3.6W(IR OFF) 、10W(IR ON) |
| Operating Environments |
0 ~ 45 °C |
| Weight |
Net weight: 350g |
| Dimensions |
190mm x 71mm x 59 mm |
| IP Rating |
IP66 |
*If the above specifications are different, please refer to the latest date
