| SYSTEM |
OPERATING SYSTEM：LINUX |
| STORAGE DEVICE/ |
BUILD IN SATA INTERFACE X 1，COMPATIBLE SATA/SATAII |
| INTERFACE |
HDD( MAX. 8TB) |
| USER INTERFACE |
DVR IR REMOTE CONTROL |
VIDEO AND OTHER I/O
INTERFACE |
ALARM OUT X1 / ALARM IN X4 (OPTIONAL) |
| HEADPHONES (SPEAKERS) SOUND OUTPUT X1 |
| ETHERNET X1 – 10/100/1000/ (IEEE 802.3 TYPE 10BASE-T / IEEE 802.3U TYPE 100BASE-TX / I)；AUTO-MDIX |
| NETWORK PROTOCOL |
IPV4、ARP、TCP、UDP、ICMP、SMTP、HTTP、PPPOE、DDNS、UPNP、DHCP |
| VIDEO FORMAT |
H.264 COMPRESSION FORMAT |
| |
E-MAP |
| LIVE / PLAYBACK |
REAL-TIME LIVE VIEW CAPABLE 4CH VGA @30FPS OR 1CH 1080P @30FPS |
| 1CH 1080P @30FPS ；4CH VGA @30FPS SYNCHRONOUS PLAYBACK |
| RECORDING QUERY: TIME SEARCH, EVENT LIST ( CAM DISPLACEMENT, ALARM I / O TRIGGERED ALARM NOTIFICATION(OPTIONAL) ) |
| PLAYBACK SPEED/ SLOW FORWARD / FAST FORWARD IN 5 DIFFERENT SPEED, PLAY FRAME BY FRAME MODE (FORWARD OR BACKWARD) |
| PENTAPLEX OPERATION: LIVE/ RECORD/ PLAYBACK |
| EVENT NOTIFICATION |
EVENT NOTIFICATION : ALARM I / O TRIGGER(OPTIONAL) , MOTION DETECTION, VIDEO LOSS, HDD ERROR |
| RECORDING MODE |
CONSTANT RECORDING |
| SCHEDULE RECORDING |
| ALARM TRIGGERED RECORDING (INCLUDE MOTION DETECTION RECORDING): COMPLETE EVENT |
| VIDEO RESERVED 5 SECONDS BEFORE AND 60 MINUTES AFTER EVENT TAKEN PLACE. |
| MANUAL RECORDING |
| SCHEDULE ALARM TRIGGERED RECORDING (INCLUDE MOTION DETECTION RECORDING): COMPLETE EVENT VIDEO RESERVED 5 SECONDS BEFORE AND 60 MINUT AFTER EVENT TAKEN PLACE.
|
| ONLY RECORDING WITHOUT LIVE (DEPENDING ON USER AUTHORITY) |
| BACKUP MANAGEMENT |
VIDEO OUTPUT FORMAT: AVI |
| THE USB MOBILE STORAGE DEVICE |
| SYSTEM MANAGEMENT |
REMOTE CLIENT SOFTWARE; LIVE, PLAYBACK SET UP BY PC(REMOTE SIDE) |
| AUTHORIZATION: MAXIMUM 10 GROUP ACCOUNTS, HIERARCHICAL AUTHORITY |
| SUPPORT 3 USERS LOG ON BY CLIENT-SIDE SOFTWARE OR BROWSER |
| SYSTEMS OPERATION RECORDS, RECORD LOGIN TIME, IP AND SELECTED VIDEO. |
| BROWSER: MS IE7-IE11 |
| SUPPORT EQUIPMENT |
SUPPORT MEGAPIXEL DTV CAMERA VIDEO |
| POWER |
DC12V / 3A |
| OPERATING TEMPERATURE |
0-45 ℃ |
| WEIGHT |
ABOUT 2.1KG |
| DIMENSION |
315MM X 220MM X 60MM (W X D X H) |
