Item

Specification

Video Input

2CH 4MP

Resolution

4MP
CH1 NTSC/PAL:30FPS/25FPS、CH2 NTSC/PAL:30FPS/25FPS

Power Consumption

DC12V input, power consumption is approx. 1A.
DC12V input, ACC OFF standby power consumption is approx.2.5mA.
Operation voltage: DC10.0v ~ DC15.6v.
Initial voltage: DC8V above.

Operation
Temperature

Operation -20℃～60℃  ( In disclosed space) .
Storing temperature: -40℃～85℃.

Storage Device

Memory card speed is recommended to be above U3, Otherwise it may causes the recording not completely.

Recording
mode

Continuous recording after power ON.

Data Content

Video, date, time, audio, GPS, external alarm trigger log, G-Sensor.

Storage Format

TS file format with universal playback software playback; the device has the function of playback.

Audio Input

Compatible With multi-function display (including microphone receiver)

Time Setting

GPS time zone auto calibration, and initialize with build-in calendar if no GPS signal.
Please do GPS time calibration after installation, time memory is kept with car battery, no battery power supply will result setting return to default, please do time calibration after connecting to power.

Display Mode

TV-Out, Wifi AP mode by APP

Size

112x28x83mm

Video System

NTSC

PAL

Image Signal Process

CMOS Image Sensor

Lens

2.9mm

Number Of Pixel

2688 (Horizontal) x 1512(Vertical) / 4.0 Mega Pixel

Horizontal Resolution

Color: 4MP/30fps

Color: 4MP/25fps

Power Supply

DC 5 ± 0.5V ( 180 mA)

Power Consumption

0.9W

Minimum Illumination

0.1 LUX

S/N Ratio

Max 36.3 dB

Electronic Shutter

Auto: 1/30NTSC(1/25 PAL)s TO 1/50,000s

Output

1 Vp-p Composite Video Output, 75 Ohms

View Angle

H:120°

Operating Temperature

- 10° C ~ + 60°C

Dimensions ( H × L )

42.5 x 60 x 53mm

Waterproof

IP66

Weight

82g
