Resolution

NTSC  1920x1080@30fps /  PAL  1920x1080 @25fps

Display mode

Single image

Simplex mode

Record/Play

Resolution

Display

1920 x 1080

Record

1920 x 1080

Backup

SD card

SD Card

YES

G-SENSOR

YES

System monitoring

Recording automatically when power is on

Built-in Supercapacitor

YES

WIFI

WIFI  Dongle

3G / 4G

3G&4G  or USB wireless network card (optional)

Power

DC 12V

Operation temperature

-21℃ ~ 60℃

Input

1. Power input cable: DC12V power input

2. Image input: video connector

3. WiFi dongle

4. 3G/4G  USB wireless network card (optional)

5. SD card slot

Power

 DC5V ±10%； 170mA

Resolution

NTSC/PAL Full HD 1920 x 1080

Max. 30FPS

Image Sensor

1/2.7”  CMOS Digital Image Sensor

View Angle

Horizontal:110 °   /  Vertical : 90 °/ Diagonal:140°

Lens

3.3mm

Temperature Tolerance

Operation -20℃～60℃ (In a disclosed space).

Storing temperature: -40℃～85℃.

Output

Power connector

Waterproof and dustproof level

IP67

Lights

4LED (WIFI、REC、GPS、POWER)

GPS

YES

Interrupted detection

YES

Input

Monitor input: GPS data, Microphone

IP Rating

IP67

Lights

2LED (WIFI、REC)

Interrupted detection

YES

Audio input

Microphone

IP Rating

IP66
