VVG-MDE50

2CH / 720P / WIFI / SD card

  • DC10~14.5V

  • -20~60°C

  • SD

Download Catalog

Product Features

  • Waterproof function
  • Micro-vehicle video recording system, 2 channels video input .
  • H.264 compression format, support 720P video resolution.
  • Low power consumption and efficient heat dissipation, no build-in Lithium battery to prevent possible danger and heat explosion.
  • Device starts recording automatically when engine is on; Device automatically save records and shutdown when engine is off.
  • Built-in supercapacitor, ensure file is well formatted and saved securely in memory card with extension recording time after engine off.
  • Capable connect with USB WiFi dongle, watch and backup live video through mobile device.
  • Acceptable custom orders.
  • Made in Taiwan

Video input

Support 2 CH AHD 720P camera

Resolution

720p

CH1+CH2: Max.60FPS

Default setting as CH1 30FPS, CH2 30FPS.

Power Consumption

(a)DC12V input, power consumption is approx. 500mA。

(b)DC12V input, ACC OFF standby power consumption is approx. 30mA.

(c)Operation voltage: DC10.0v ~ DC14.5v。

(d)Initial voltage: DC11v above.

Delay recording

(a)ACC OFF, support software setting ACC delay shut down device function.

(b)Built-in super capacitor extension power supply and delay recording about 3 sec
ensure records write back to SD card.

Operation

Operation Temperature:-20℃～60℃ (Non-confined spaces with natural ventilation)

Temperature

Storing temperature: -40℃～85℃.

Storage Device

Class 10, 8GB storage and above SDHC Card

Recording mode

Auto recording after power ON.

Records

Video, date.

Storage Format

Specific file format, play video with a dedicated player; has local playback function.

Some specific devices do not have remote control receiver and local playback function.

Audio input

N/A

Time Setting

Built-in perpetual calendar clock with button battery to maintain RTC time, time can be re-calibrated using the playback software.

Display Mode

(a)USB WiFi Real-time display (optional)

Output device

(a)Green light flashing: recording.

(b)Red light: install or set incorrect.

(c)Blue light: WiFi connection. (optional) Higher flashing frequency for software updating, please do not cut off device power.

Input

(a)Power and signal input:

     i.Power input DC12V

     ii.ACC signal: power input range DC10.0v ~ DC14.5v

(b)Video input: please protect with waterproof tape on connectors after wiring.

(c)USB WiFi slot (optional)

(d)SD card slot
