Mobile Surveillance

Dash Cam

VVN-CBE07F

2CH / 1080P / WIFI / H.264 / SD card / GPS

  • H.264

  • -15~65°C

  • 120º (F)

  • MIC Built-in

  • G-Sensor

  • GPS

  • MAP

  • Micro SD

  • 120° B

Download Catalog

Product Features

  • Apply for service and private transportation needs, such as taxis, cement trucks, cargo trucks, road tankers, school buses, police cars, armored cars, ambulances, fire trucks, SUVs, and RVs etc.
  • Sensitive, extra low lux and high resolution CMOS Image Sensor.
  • Forward-facing view angle approx. 120 degrees. cabin view angle approx. 120 degrees.
  • Built-in 1.5F gold capacitor to preserve the images while encountering accidental collisions.
  • Simultaneously record interior and exterior driving images.
  • Record driving route, footage, audio, G-Sensor, and GPS data. (Optional)
  • Route recorded, displayed on playback, compatible with Google Maps
  • Micro SD Card applied, Class 10 or above is recommended.
  • The G-sensor sensitivity can be adjusted according to the vehicle's and road's situations. The system will start emergency recording and keep the files from being overwritten when strong impacts are detected.
  • Professional file format. Without built-in lithium batteries, excluding no possibility of an explosion or heat.
  • WIFI on board for live streaming, video download and backup

 Sensor

Forward-facing camera 1080P CMOS Sensor
In-vehicle camera 1080P CMOS Sensor

Camera view angle (Diagonal)

Forward-facing camera view angle approx.120°
Interior-facing camera view angle approx.120°

 Voltage

(a) Supports 12V input, above 1000mA
(b) Built-in 1.5F Gold Capacitor for video filling.

Recording type

Resolution 1920x1080, up to 30fps @ NTSC & 25Fps @PAL for both forward-facing and interior cameras.
Auto recording when the system boots; the interior-facing camera can be shut down by software.

Record content

Date, Time, Image, Sound, G-sensor data, GPS data (optional)

Storage format

(a) Specific format with software player
(b) H.264 compression

Microphone

Built-in monaural high-sensitivity sound-receiving microphone

Time setting

Time calibration by GPS, the built-in calendar clock takes over when there is no GPS signal.

G-Sensor

Built-in 3D G-Sensor

GPS

Could apply with external G-MOUSE for better GPS reception.
Satellite fix to record the driving route.

WiFi

USB WIFI Dongle(2.4G HZ) (Optional)

Operating temperature

-15ºC~65ºC

Storage Device

 It is recommended to use an SDHC/SDXC card class 10 and above (32G and above).

Output/input device

(a) FORCE: force button, dim light as assistance for night use
(b) Red light: Recording light (the flashing rate will be higher when forced recording.)
(c) Green light: GPS indicator (flashing indicates that the 3D positioning is not settled,
constantly lit for settled.)
(d) Blue light: WiFi indicator (flashing for failed WiFi connection, constantly lit for
successful connection.)
(e) EXT: Extension external hole for GPS Mouse
Note: When in night mode, the IR activates, and the LED indicator lights will dim.
