| Operation System |
SOC + ARM Cortex M3 |
| Video Compression |
H.264/H.265 High Profile |
| Operation System |
Embedded Linux + MCU firmware |
| Communications |
4G Cat.4 + AGPS ( mini-PCIe 4G Module)
Antenna : External (SMA x2) |
| GPS |
(1)GPS,GLONASS and AGPS Supported within 4G Module.
Antenna : External (SMA x1)
(2)GPS antenna removed detection. |
| Video Inputs /Output |
Inputs : 1080P30 x 4Channels (Micro-Dins). |
| Output : CVBS x 1 (Micro-Din) and VGA x 1 |
| Power output : 12V/750 mA with Recoverable Fuse |
| for Micro-Dins. |
| I/O(standard) |
(1)Analog Input x 2 |
| a.Voltage Range: 0-50V (e.g. Fuel detection) |
| b.Resolution: 12 bit |
| (2)Digital Input (max. 50V) x 13 |
| a.Ignition High Active(ACC) x1 |
| b.Tachometer RPM x1 |
| c.Speed x1 |
| d.Positive / Negative Trigger x 10 |
| (3)Digital Output (Current Output Mode) x2 |
a.Maximum Current Configuration up to 0.5
|
| Ampere Hardwire Voltage Range+3V to 50V |
| Audio Input /Output |
Support Condenser Microphone and Speaker(4Ω/2W)
(Doesn’t need Amplifier circuit for both MIC and Speaker) |
| Communication Interface |
(1)CAN BUS (2 Wires) x 1
(2)RS232 (2 Wires) x 2
(3)Dual SIM Cards (switchable by MCU)
External(Full-size 1.8V)
(4)eSIM on board (optional)
(5)RJ45 (optional)
(6)One-Wire x1(e.g.Temperature Sensors, iButtons)
max.128 |
| Recording Resolution |
1080P / 720P / 960H |
|
|
SD Card (Above Class 10) x 2 |
| Indicate LEDs |
REC/Power(Red LED), Internet(Green LED), GPS(Blue LED) |
| Buzzer Sounding |
Supported |
| Sensor |
Built in 6 axis sensor for motion detection
(G Sensor function is included.)
|
| Battery Type |
Lithium lion: 3.7V / 2200mA (Built in with Charger) |
| Power consumption |
(1)Working:
a.8-60 VDC, 6W (12V,0.6A), Excluding both Cameras
and Screen (Power Protected when over 60V, Max.65V)
b.Main Power removed detection.
(2)Standby: Less Than 10mA@ >12.6V.
(3)+12VOutput: Max. 12V @ 1.35A. |
| Power Supply |
DC 8V~60V |
| USB Socket |
(1)USB-WiFi Dangle (optional)
a.Support WiFi (AP mode) 802.11b/g/n
b.Applications: WiFi Connection
(2)USB-B.T. Dangle (optional)
a.Support Version:V4.x
b.Applications: Configuration & Firmware Update
(3)RJ45 Network Module (optional)
a.Streaming Share (DHCP)
b.Hardwire DHCP Connection
c.Maximum Shared Bandwidth Subject to Hardware
Competence |
| Working Mode |
(1)Regular Work Mode: GPS Localization + Digital Recording.
(2)Power Saving Mod：Timer / Alarm Trigger / 6-Axis
Sensor / Wake-up Standby Cameras |
