item
|
Description
|
Model
|
VVH-MDE46
|
Video format
|
NTSC / PAL
|
Operating system
|
Embedded Linux
|
Video input
|
x4 cameras
|
Camera power output
|
5V / 750mA x4 power
|
Video output
|
(RCA or VGA) x1 video output
|
Audio input
|
x1 audio input
|
Audio output
|
x1 audio output
|
Alarm I/O
|
x4 alarm input
|
Operation interface
|
GUI
|
Language
|
English / Traditional Chinese / Simplified Chinese
|
Recording frame
|
1080P @CH/15FPS / (720p/D1) @CH/30FPS
|
Display mode
|
Full screen / Quad
|
Operation mode
|
Recording / Playback
|
Record resolution
|
1920x1080 / 1280x720 / 720x480
|
Storage
|
SD card
|
Search
|
Mode
|
Time / Date / Event
|
Full screen
|
Yes
|
LED
|
3 LED (LAN, REC / Power, GPS)
|
Video loss alert
|
Yes
|
GPS
|
G-MOUSE
|
G-SENSOR
|
Yes
|
RS232
|
Yes
|
WiFi dongle
|
External P23 USB wireless network card
|
IR
|
Yes
|
Supercapacitor
|
Built- in , 3 seconds
|
Watch dog
|
Auto reboot after power cut
|
Power spec
|
(1) DC 8V~36V (2) ACC power-off delay is set by software (3) DC 12V OUT
|
