IP Surveillance System

IP Camera


1080P / IP66 / Bullet / H.265+

  • 0 LUX

  • P.O.E

  • LENS2.8~12MM

  • 40M

  • 56LEDs

  • 1/2.8"CMOS

  • 0~45°C

Download Catalog

Product Features

  • SONY 5M Pixels 1/2.8" CMOS Sensor with excellent image quality
  • Real time H.265+/H.264 /MJPEG Multi-Mode compression (Dual Codec)
  • Resolution 2560*1920 @ 15fps/s
  • 56pcs IR LED, IR Distance 40M
  • Support ONVIF international standard, best compatibility and integration
System Flash:16MB
Sensor Full HD High Quality 1/2.8” SONY CMOS Image Sensor
Lens Vari-focal 2.8~12mm F1.8
IR Cut Removable IR Cut filter
Lux 0 Lux(IR ON)
LED 56pcs IR LED
Compression H.265+: 2560x1920 at 15fps
H.265+: 2048x1536 at 20 fps
H.265+: 1920x1080 at 30fps
H.265+、H.264、JPEG Multi-mode
compression (Dual Codec)
Multi-mode compression streaming
Video Adjustment Resolution、Quality and bit rate
Time、Date or custom text and it’s position
Brightness, Contrast, Saturation and Sharpness
Network Interface 10 /100 Mbps RJ-45
Browser Microsoft Internet Explorer 6.0 or above
Safari, Chrome or Firefox
Alarm & Event notification Motion Detection
E-mail notification or upload file to FTP
User Max. 8 users for live view simultaneously
User Authorization
OTA OTA for Firmware upgrade
I/O Port RJ-45, DC12V
Power DC12V
Power Consumption 3.6W(IR OFF) 、18W(IR ON)
Weight N.W.:1135g
Dimension 260mm x 118mm x 110mm
Operating Environments 0 ~ 45 °C
IP Rating IP66

Simliar Product

Update Date 2021/12/09 VIG-US729V-D6 VIG-US729AV VIG-UJ729V-Z5
Resolution 5MP 2MP 2MP
Pick Up Element 1/2.8" CMOS 1/2.9" CMOS 1/3" CMOS
LENS Varifocal 2.8~12mm Varifocal 2.8~12mm Varifocal 2.8~12mm
IR Range 40m
Sensitivity 0.lux
Waterproof IP66

*If the above specifications are different, please refer to the latest date
