Wearable Recorders
Product Features
Recorder specifications
| Video input | 1 channel 1080P 5V camera support |
| Recording resolution | Video resolution 1080p Recording frame rate 30fps/ch |
| Power | (a) Current consumption 0.95A and power less than 4.75W in condition of DC5V (b) Operating Voltage ：DC4.75V ~ DC5.25V |
| Operation temperature | Operating Temperature：-20℃ ~ 60 ℃ (In disclosed space) Storing temperature：-40℃ ~ 85℃ |
| Storage | Minimum requirements : SDHC Card Class 10 and capacity of 8GB |
| Recording type | Automatically constant recording after reboot |
| Record content | Image, date and time, sound, touch signal, GPS |
| Storage format | Specific file formats must be played with dedicated playback software |
| Voice input | MIC |
| Time setting | Perpetual calender clock built in |
| Output device | (a) Red light: Red flashing for 2 seconds means recording, 1 second flashing means compulsory recording, fast flashing means firmware update, please do not power off. Long red is the device error light (b) Blue light: Connecting light, flashing every 2 seconds means searching, steady on means connecting (c) Green light: GPS positioning light, flashing every 2 seconds,it means searching, if it is steady on, it means it has been located (d) Press and hold the TOUCH PANEL for more than 5 seconds and release it to turn off all indicator lights |
| Input device | (a) Power and signal input line: power supply DC5V input,USB TypeA (power bank) (b) Video input: Micro DIN (c) Display input: MIC voice input (d) SD card slot (e) Micro SIM card slot |
| Accessory | (a) power cable (b) Camera (c) GPS Atnenna (d) Pocket |
| Recording Resolution | NTSC 1920x1080@30fps / PAL 1920x1080@25fps |
| Image Sensor | 1/2.9” CMOS Digital Image Sensor |
| View Angle | 140 degrees wide angle |
| Lens | 2.1 mm |
| Output connector | Micro din waterproof connector |
| IP Rating | IP66 |
