Pick Up Element
|
1/2.5" CMOS sensor
|
|
Video System
|
NTSC / PAL
|
|
Image Signal Process
|
Digital Signal Processor
|
|
Lens
|
3.6mm
|
|
Number Of Pixel
|
2608 (Horizontal) x 1952(Vertical)
|
|
Horizontal Resolution
|
5M@20fps
|
|
Power Supply
|
DC 12 ± 1V
|
|
Power Consumption
|
120mA (IR Off)；800mA (IR On)
|
|
ICR
|
Support
|
|
Electronic Shutter
|
Auto
|
|
White Balance
|
Auto
|
|
Gain Control
|
Auto
|
|
S/N Ratio
|
≥50dB
|
|
Day Night Auto Switch
|
Support
|
|
LEDs
|
12 PCS
|
|
IR Range
|
100M
|
|
IR Wavelength
|
850nm
|
|
Minimum Illumination
|
0.2Lux
|
|
OUTPUT
|
AHD or CVBS or TVI or CVI
(Default setting: AHD Mode)
|
|
Language
|
English / Simplified Chinese / Traditional Chinese /
Russian / Italian / Portuguese
|
|
IP Rating
|
IP66
|
|
Operating Temperature
|
-20℃~85℃
|
|
Dimensions (H×W×D)
|
149mm x 115mm x 303mm
|
|
Weight
|
About 1000g
|
Simliar Product
| Update Date 2022/01/28 |
VCF-5K02H |
VCF-5M02H |
VCN-4K02H-AF |
VCN-SH5902H-AF |
VCF-5502H |
| Resolution |
5MP |
5MP |
4K |
1080P |
1080P |
| Pick Up Element |
1/2.5" CMOS |
1/2.5" CMOS |
1/2" CMOS |
1/2.8" CMOS |
1/3" CMOS |
| LENS |
3.6mm/3.3-12mm |
2.8-12mm |
3.6-11mm(AF) |
3.6-11mm(AF) |
3.6mm |
| LEDS |
12 PCS |
| IR |
✓ |
| IR Wavelength |
850nm |
| IR Range |
100m |
| Sensitivity |
0.2Lux |
0.1Lux |
0.1Lux |
0.01Lux |
0.1Lux |
| Starlight Color |
|
|
|
• |
|
| AF |
|
|
• |
• |
|
| OUTPUT |
AHD、CVBS、TVI、CVI |
AHD、CVBS、TVI、CVI |
AHD、TVI/500W CVI/400W、CVBS |
AHD、CVBS、TVI、CVI |
AHD、CVBS、TVI、CVI |
| Waterproof |
IP66 |
*If the above specifications are different, please refer to the latest date
