Video System
|
NTSC PAL
|
|
Pick Up
|
1/2.8" SONY CMOS Sensor
|
|
Number of Pixel
|
1920(H)×1080(V)
|
|
Effective Pixels
|
2.0 Mega Pixel
|
|
Resolution
|
1080P
|
|
Sync System
|
Internal
|
|
Scanning system
|
2 : 1 Interlace
|
|
Sensitivity
|
0.01 LUX
|
|
S/N Ratio
|
≥50dB
|
|
Auto Gain Control
|
Auto
|
|
Mirroring
|
Optional(BV)
|
|
White Balance
|
Auto
|
|
Electronical Shutter
|
Auto: 1/30NTSC(1/25 PAL)S TO 1/50,000S
|
|
Video Output
|
1 Vp-p Composite Video Output, 75 Ohms
|
|
Power Supply
|
DC 12.0V
|
|
Power Consumption
|
80 mA (IR OFF) / 150mA (IR ON)
|
|
Lens
|
2.8mm
|
|
View Angle
|
H: 90°
|
|
Operating Temperature
|
- 10° C ~ + 60°C
|
|
Dimensions (H x W x D)
|
57.6 × 52.4. × 55.5 mm
|
|
LEDs
|
6PCS
|
|
IR Range
|
3M
|
|
IR Wavelength
|
850 nm
|
|
Waterproof
|
IP68
|
|
Simliar Product
| Update Date 2022/01/25 |
AVM-S252C |
AVM-S352C |
AVM-H252A |
| Resolution |
1080P |
960H |
| Pick Up Element |
1/2.9" SONY CMOS |
1/2.9" SONY CMOS |
1/4" CMOS |
| Lens |
2.8mm |
2.6mm |
| LEDS |
6 PCS |
| IR |
✓ |
| IR Range |
3M |
| Sensitivity |
0.1 LUX |
0.01 LUX |
0.1 LUX |
| View Angle |
H 90° |
H 110° |
H 90° |
| Waterproof |
IP68 |
| Update Date 2022/01/25 |
AVM-S252B |
AVM-H252B |
AVM-H251B |
| Resolution |
720P |
| Pick Up Element |
1/2.9" SONY CMOS |
1/4" CMOS |
1/4" CMOS |
| Lens |
2.6mm |
| LEDS |
6 PCS |
| IR |
✓ |
| IR Range |
3M |
| Sensitivity |
0.1 LUX |
| View Angle |
H 90° |
| Waterproof |
IP68 |
|
*If the above specifications are different, please refer to the latest date
