Pick Up Element
|
1/3" CMOS sensor
|
|
Video System
|
NTSC / PAL
|
|
Image Signal Process
|
Digital Signal Processor
|
|
Lens
|
3.6mm
|
|
Number Of Pixel
|
2560 (Horizontal) x 1944(Vertical)
|
|
Horizontal Resolution
|
5MP@20fp/12.5fps
2MP@25fp/30fps
|
|
Power Supply
|
DC 8~28V
|
|
Power Consumption
|
120mA(IR Off)；330mA(IR On)
|
|
ICR
|
Support
|
|
Format
|
25FPS / 30FPS / PAL / NT
|
|
Audio
|
TVI support
|
|
S/N Ratio
|
≧55dB
|
|
White Balance
|
Auto
|
|
Gain Control
|
Auto
|
|
Gamma correction
|
Auto
|
|
Day Night Auto Switch
|
Support
|
|
LEDs
|
4 PCS
|
|
IR Range
|
30M
|
|
IR Wavelength
|
850nm
|
|
Minimum Illumination
|
0.1LUX
|
|
OUTPUT
|
AHD/TVI/CVI/CVBS (Default setting: TVI Mode)
|
|
Language
|
ENGLISH//CHINESE /TRADITONAL CHINESE
|
|
IP Rating
|
IP66
|
|
Operating Temperature
|
-20℃~50℃
|
|
Dimensions (H×W×D)
|
190mm x 71mm x 59 mm
|
|
Weight
|
About 310g
|
Simliar Product
| Update Date 2021/12/07 |
VCF-5M60U |
VCF-5560U |
VCT-5660U |
| Resolution |
5MP |
1080P |
1080P |
| Pick Up Element |
1/2.8" CMOS |
1/3" CMOS |
1/2.9" CMOS |
| LENS |
3.6mm |
| LEDS |
4 PCS |
| IR |
✓ |
| IR Wavelength |
850nm |
| IR Range |
30m |
| Sensitivity |
0.1Lux |
F1.2 0.003 LUX / 200MV |
| OUTPUT |
AHD、CVBS、TVI、CVI |
| Waterproof |
IP66 |
| Update Date 2022/08/25 |
VCF-5G60U-A |
VCN-SH5960U |
VCN-S5960U |
| Resolution |
5MP |
1080P |
1080P |
| Pick Up Element |
1/3" CMOS |
1/2.8" CMOS |
1/2.8" CMOS |
| LENS |
3.6mm |
| LEDS |
4 PCS |
| IR |
✓ |
| IR Wavelength |
850nm |
| IR Range |
30m |
| Sensitivity |
0.1Lux |
0.01Lux |
| Starlight Color |
|
✓ |
|
| OUTPUT |
AHD、CVBS、TVI、CVI |
| Waterproof |
IP66 |
*If the above specifications are different, please refer to the latest date
