Lens Specs
(Zoom LENS)

Optical Zoom

30X

Focus

4.7-141mm, Auto Focus

Least Focus Distance

1 meter (Small Angle))

Aperture (F)

F1.5~F4.0 (wide) ‒ F5.0(Tele)

Viewing Angle

-3.9°~60°(Horizontal)；1.8°~34°(vertical)

Sensor Specs

Color Mode

Color(Day) / B&W(Night) Automatic Switching

Scanning System

1/2.8" 2MP Sony Starvis CMOS sensor

Effective Pixel (H×V)

2M pixels (1920 X 1080)

Resolution

1080P30 ( NTSC ) / 1080P25 ( PAL ) Output

LUX

Color : 0.005 Lux @ 1/30Sec,F1.6 ,50IRE
B/W : 0.001 Lux @ 1/30Sec ,F1.6 ,50IRE

Imagine
Processing
Features

Digital Zoom

Off/On(16X) (480x with optical zoom)

Shutter

Auto/Flicker/Manual(1/5~1/33000)

AGC

x0 ~ x20

Sensitive Gain

X0 ~ x10

White Balance

AUTO / Acutest / Preset / Manual

De-noise

2D、3D

MIRROR

Horizontal, vertical & Flip

SHARPNESS

0 ~ 10

High Light Compensation

WDR、BLC、HSBLC(High Light Mask)

Special Features

De-fog、DIS、MOTION、FREEZE、Day/Night PRIVACY、Slow-Shutter

Compression Format

H.264 (1920 x 1080) @max. 60fps

Transmission
Specs

Interface

10/100 Mbps Ethernet、RJ-45
Support H.264/AVC codec BP/MP/HP、level 4.1、 Max. 60fps
Support H.265/HEVC codec MP、level 5.0、 Max. 60fps

Protocol

IPv4,TCP/IP, DHCP, HTTP, FTP, SMTP,RTSP,SNTP,DNS

Browser

Microsoft Internet Explorer 6.0 later version

Text Display Function(Pre-OSD)

Time, date, or custom text display and can be set to display position

control via IE

Speed dome/OSD MENU  all functions can be controlled ( compatible with keyboard KB-100)

Control Specs

PT Speed (Full Cycle)

Over 1 Second

Horizontal / Vertical Speed

240°/S / 180°/S

Horizontal Rotation Range

360° continuous

Vertical Rotation Range

0°~90°

Camera ID (Pre-set Point)

256 Points (Max.)

Pre-set Point Variance

±0.01°

Alarm

1 Channel input & 1 Channel output

IR LED Distance

12pcs High power IR LED over 150 M (Max.)

Build-in Fan

Temperature controlled

Power Supply

AC24V@3A / 40W (Max.)

Operation Temperature

-10℃ ~ +50℃

Humidity

0 ~90%RH

Environment Protection Level

IP66, All weather 3rd party enclosure, Build-in fan, All day recording,
3000V lighting protection, Serge Protection.
